Fortinet Hw Fs-m426e-fpoe (FSM426EFPOE)
Model: FSM426EFPOE
Fortinet Hw Fs-m426e-fpoe (FSM426EFPOE)
Model: FSM426EFPOE
-
HW FS-M426E-FPOE
-
Out Of Stock
Product Description
Layer 2/3 FortiGate switch controller compatible PoE+ switch with 16 x GE RJ45 ports, 8 x MultiGIG 2.5 GE UPOE (60W) capable RJ45 ports, 2 X MulitGiG 5GE RJ45 ports, 4X SFP+, with automatic Max 421W POE output limit
Product Specs
Manufacturer
FortinetCategories
Fortinet Computer AccessoriesFortinet Networking, Cables & AccessoriesFortinet Network SwitchesManufacturer Stock No.
FS-M426E-FPOEMPN
FTNFSM426EFPOEModel#
FSM426EFPOEUNSPSC Code
0Information
Product Description: Fortinet FortiSwitch M426E-FPOE - switch - 16 ports - managed - rack-mountableDevice Type: Switch - 16 ports - L3 - managed
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 16 x 10/100/1000 (PoE+) + 8 x 100/1000/2.5G (PoE++) + 2 x 100/1000/2.5G/5G + 4 x 1 Gigabit / 10 Gigabit SFP+
Power Over Ethernet (PoE): PoE++
PoE Budget: 420 W
Performance: Switching capacity: 172 Gbps ¦ Packets per second: 255 Mpps ¦ Latency: 1 µs
Capacity: Virtual interfaces (VLANs): 4000 ¦ Link aggregation groups: 8 ¦ Packet buffer size: 2 MB ¦ Routing entries: 64 ¦ Host entries: 4000 ¦ ACL entries: 512
MAC Address Table Size: 16K entries
Jumbo Frame Support: Yes
Routing Protocol: RIP-2, IGMP, VRRP, OSPFv2, Bidirectional Forwarding Detection (BFD), MSTP, RSTP, STP
Remote Management Protocol: SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, DHCP, IPv4, IPv6, RSTP, RADIUS
Features: Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, SNTP support, sFlow, STP support, DHCP snooping, TDR, LLDP support, DHCP client, static routing, STP PortFast, cloud managed, ToS, DSCP support, Storm Control, Link Aggregation, MIB II, Root Guard, Private VLAN, VLAN Tagging, IP forwarding support, Telnet server, BPDU Guard, LAG
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.1AX, IEEE 802.3bz, IEEE 802.3bt
Power: AC 120/230 V (50/60 Hz)
Dimensions (WxDxH): 17.3 in x 16.1 in x 1.7 in
Weight: 13.01 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 16 ports - L3 - managed
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 16 x 10/100/1000 (PoE+) + 8 x 100/1000/2.5G (PoE++) + 2 x 100/1000/2.5G/5G + 4 x 1 Gigabit / 10 Gigabit SFP+
Power Over Ethernet (PoE): PoE++
PoE Budget: 420 W
Performance: Switching capacity: 172 Gbps ¦ Packets per second: 255 Mpps ¦ Latency: 1 µs
Capacity: Virtual interfaces (VLANs): 4000 ¦ Link aggregation groups: 8 ¦ Packet buffer size: 2 MB ¦ Routing entries: 64 ¦ Host entries: 4000 ¦ ACL entries: 512
MAC Address Table Size: 16K entries
Jumbo Frame Support: Yes
Routing Protocol: RIP-2, IGMP, VRRP, OSPFv2, Bidirectional Forwarding Detection (BFD), MSTP, RSTP, STP
Remote Management Protocol: SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, DHCP, IPv4, IPv6, RSTP, RADIUS
Authentication Method: Secure Shell (SSH), RADIUS
Features: Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, SNTP support, sFlow, STP support, DHCP snooping, TDR, LLDP support, DHCP client, static routing, STP PortFast, cloud managed, ToS, DSCP support, Storm Control, Link Aggregation, MIB II, Root Guard, Private VLAN, VLAN Tagging, IP forwarding support, Telnet server, BPDU Guard, LAG
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.1AX, IEEE 802.3bz, IEEE 802.3bt
RAM: 1 GB DDR4 SDRAM
Flash Memory: 256 MB
Status Indicators: Status
Interfaces: 16 x 1000Base-T RJ-45 PoE+ ¦ 8 x 1/2.5GBase-T RJ-45 4PPoE ¦ 2 x 1/5GBase-X RJ-45 ¦ 4 x 10GBase-X SFP+ ¦ 1 x management RJ-45 ¦ 1 x console RJ-45
Power Device: Internal power supply
Voltage Required: AC 120/230 V (50/60 Hz)
Power Consumption Operational: 442 Watt
MTBF: >10 years
Compliant Standards: UL, VCCI, BSMI, CB, FCC, RoHS2, RCM
Width: 17.3 in
Depth: 16.1 in
Height: 1.7 in
Weight: 13.01 lbs
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 °F
Max Operating Temperature: 122 °F
Humidity Range Operating: 5 - 95% (non-condensing)
Min Storage Temperature: -4 °F
Max Storage Temperature: 158 °F
COO: TAIWAN
TAA compliance: Yes
