Cisco Catalyst 9200l 24-port Data Only (C9200L24T4XEDU)
Model: C9200L24T4XEDU
Cisco Catalyst 9200l 24-port Data Only (C9200L24T4XEDU)
Model: C9200L24T4XEDU
-
Catalyst 9200L 24-port data only
-
Special order arrives within 3-7 weeks.
Product Description
CATALYST 9200L 24-PORT DATA ONLY, 4X10G UPLINKS, K12
Product Specs
Manufacturer
CiscoManufacturer Stock No.
C9200L-24T-4X-EDUMPN
CSCC9200L24T4XEDUModel#
C9200L24T4XEDUUPC Code
889728205214UNSPSC Code
0Information
Product Description: Cisco Catalyst 9200L - switch - 24 ports - managed - rack-mountableDevice Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)
Performance: Stacking bandwidth: 80 Gbps ¦ Switching bandwidth: 128 Gbps ¦ Forwarding rate: 190.4 Mpps
Capacity: Virtual networks: 4 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Flexible NetFlow entries: 16000 ¦ Packet buffer size: 6 MB ¦ VLAN IDs: 1024 ¦ Switched virtual interfaces (SVIs): 512
MAC Address Table Size: 16000 entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Features: ARP support, STP support, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, CoS, FNF, Cisco StackWise-160 technology, DSCP support, MACsec support, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3bz
Power: AC 100-240 V (50 - 60 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 17.5 in x 11.3 in x 1.7 in
Pricing Type: K-12 education
Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)
Performance: Stacking bandwidth: 80 Gbps ¦ Switching bandwidth: 128 Gbps ¦ Forwarding rate: 190.4 Mpps
Capacity: Virtual networks: 4 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Flexible NetFlow entries: 16000 ¦ Packet buffer size: 6 MB ¦ VLAN IDs: 1024 ¦ Switched virtual interfaces (SVIs): 512
MAC Address Table Size: 16000 entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Encryption Algorithm: 128-bit AES
Features: ARP support, STP support, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, CoS, FNF, Cisco StackWise-160 technology, DSCP support, MACsec support, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3bz
RAM: 2 GB
Flash Memory: 4 GB
Interfaces: 24 x 10/100/1000 Base-T RJ-45 ¦ 4 x 10GBase-X SFP+ uplink ¦ 1 x network stack device ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45
Power Device: Internal power supply - hot-plug
Max Supported Qty: 2
Power Redundancy: Optional
Power Provided: 125 Watt
Voltage Required: AC 100-240 V (50 - 60 Hz)
MTBF: 525,990 hours
Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35
Pricing Type: K-12 education
Width: 17.5 in
Depth: 11.3 in
Height: 1.7 in
Humidity Range Operating: 5 - 90% (non-condensing)
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 5 - 90% (non-condensing)
COO: MALAYSIA
TAA compliance: No
