Cisco Catalyst 9500 32-port 40/100g Only, Advantage (C950032QCA=)
Model: C950032QCA
Cisco Catalyst 9500 32-port 40/100g Only, Advantage (C950032QCA=)
Model: C950032QCA
-
CATALYST 9500 32-PORT 40/100G ONLY, ADVANTAGE
-
Special order arrives within 3-7 weeks.
Product Description
Catalyst 9500 32-port 40/100G only, Advantage
Product Specs
Manufacturer
CiscoManufacturer Stock No.
C9500-32QC-A=MPN
CSCC950032QCAModel#
C950032QCAUNSPSC Code
0Information
Product Description: Cisco Catalyst 9500 - Network Advantage - switch - 32 ports - managed - rack-mountableDevice Type: Switch - 32 ports - L3 - managed
Enclosure Type: Rack-mountable 1U
Subtype: 40 Gigabit Ethernet
Ports: 32 x 40 Gigabit QSFP
Performance: Switching capacity (full duplex): 3.2 Tbps ¦ Forwarding rate: 1 Bpps
Capacity: Routing table entries: 80000 ¦ Indirect IPv4 routes: 212000 ¦ Host IPv4 routes: 90000 ¦ Indirect IPv6 routes: 212000 ¦ Host IPv6 routes: 90000 ¦ Multicast scale: 32000 ¦ QoS ACL scale: 16000 ¦ Security ACL scale: 270000 ¦ FNF entries: 96000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000
MAC Address Table Size: 64K entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, IS-IS, RIP-2, BGP, EIGRP, IGMP, VRRP, PIM-SM, PIM-SSM, MSDP, RIPng, MPLS
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP, SNMP 3, SNMP 2c, TFTP, NETCONF, RESTCONF
Features: DHCP support, NAT support, PAT support, trunking, MPLS support, NSF, SSO, CBWFQ, WRED, STP support, VRRP support, ACL support, QoS, NSR, RSPAN, HSRP support, VRF, MLD, FNF, MSDP, MACsec support, CoPP, integrated Wireshark, VLAN Double Tagging (Q-in-Q), EoMPLS, H-VPLS, Private VLAN, L3VPN support, CoAP support, SPAN
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba
Power: AC 120/230 V (50 - 60 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 17.5 in x 18 in x 1.7 in
Weight: 21.85 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 32 ports - L3 - managed
Enclosure Type: Rack-mountable 1U
Subtype: 40 Gigabit Ethernet
Ports: 32 x 40 Gigabit QSFP
Performance: Switching capacity (full duplex): 3.2 Tbps ¦ Forwarding rate: 1 Bpps
Capacity: Routing table entries: 80000 ¦ Indirect IPv4 routes: 212000 ¦ Host IPv4 routes: 90000 ¦ Indirect IPv6 routes: 212000 ¦ Host IPv6 routes: 90000 ¦ Multicast scale: 32000 ¦ QoS ACL scale: 16000 ¦ Security ACL scale: 270000 ¦ FNF entries: 96000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000
MAC Address Table Size: 64K entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, IS-IS, RIP-2, BGP, EIGRP, IGMP, VRRP, PIM-SM, PIM-SSM, MSDP, RIPng, MPLS
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP, SNMP 3, SNMP 2c, TFTP, NETCONF, RESTCONF
Encryption Algorithm: 256-bit AES
Features: DHCP support, NAT support, PAT support, trunking, MPLS support, NSF, SSO, CBWFQ, WRED, STP support, VRRP support, ACL support, QoS, NSR, RSPAN, HSRP support, VRF, MLD, FNF, MSDP, MACsec support, CoPP, integrated Wireshark, VLAN Double Tagging (Q-in-Q), EoMPLS, H-VPLS, Private VLAN, L3VPN support, CoAP support, SPAN
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba
Processor: 1: 2.4 GHz
RAM: 16 GB
Flash Memory: 16 GB
Built-in Devices: RFID tag
Interfaces: 32 x 100Gbit/40Gbit LAN QSFP ¦ 2 x USB 3.0
Power Device: Internal power supply - hot-plug
Installed Qty: 1
Max Supported Qty: 2
Power Redundancy: Optional
Power Redundancy Scheme: 1+1
Power Provided: 650 Watt
Voltage Required: AC 120/230 V (50 - 60 Hz)
MTBF: 307,200 hours
Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
Software Included: Cisco IOS XE 16.8.1
Width: 17.5 in
Depth: 18 in
Height: 1.7 in
Weight: 21.85 lbs
Service & Support: Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 5 - 90% (non-condensing)
Min Storage Temperature: -4 °F
Max Storage Temperature: 149 °F
Humidity Range Storage: 5 - 95% (non-condensing)
COO: Inquire
TAA compliance: Inquire
