Team Group Lsi Sas 9300 4i4e 4i/4e Port 12gb/s (H52551500)
Team Group Lsi Sas 9300 4i4e 4i/4e Port 12gb/s (H52551500)
-
LSI SAS 9300 4i4e 4i/4e PORT 12GB/S
-
Out Of Stock
Product Description
LSI Logic SAS 9300 4i4e SGL 6Gb/s SAS PCI Express 3.0 x8 Plug in Card 2 Total SAS Port(s) 1 SAS Port(s) Internal 1 SAS Port(s) External
Product Specs
Manufacturer
Team GroupManufacturer Stock No.
H5-25515-00MPN
PLSH52551500Model#
H52551500UNSPSC Code
0Information
Product Description: Avago TDSourcing SAS 9300-4i4e - storage controller - SATA 6Gb/s / SAS 12Gb/s - PCIe 3.0 x8Device Type: Storage controller - plug-in card - low profile
Bus Type: PCIe 3.0 x8
Interface: SATA 6Gb/s / SAS 12Gb/s
Data Transfer Rate: 12 Gbit/s
Supported Devices: Hard drive, tape drive, solid state drive
Channel Qty: 8
Max Storage Devices Qty: 1024
System Requirements: Linux, FreeBSD, Red Hat Linux, SuSe Linux, Microsoft Windows, Oracle Solaris, VMware ESX
Dimensions (WxDxH): 6 in x 2.6 in
Manufacturer Warranty: 3-year warranty
Device Type: Storage controller - plug-in card - low profile
Host Bus: PCIe 3.0 x8
Interface: SATA 6Gb/s / SAS 12Gb/s
Data Transfer Rate: 12 Gbit/s
Supported Devices: Hard drive, tape drive, solid state drive
Channel Qty: 8
Max Storage Devices Qty: 1024
Processor: LSI LSISAS3008
Interfaces: 1 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) (external) ¦ 1 x SAS 12Gb/s - 4 x Mini SAS HD (SFF-8643) (internal)
Included Accessories: Low-profile bracket
Features: Fusion MPT 2.5
MTBF: 2,800,000 hours
Compliant Standards: EN 60950, EN55022, ICES-003, EN55024, AS/NZS 3548, RoHS, WEEE, FCC CFR47, V-3/02.04, N-B 2-0001-404
OS Required: Linux, FreeBSD, Red Hat Linux, SuSe Linux, Microsoft Windows, Oracle Solaris, VMware ESX
Service & Support: Limited warranty - 3 years
Depth: 6 in
Height: 2.6 in
Min Operating Temperature: 32 °F
Max Operating Temperature: 131 °F
Humidity Range Operating: 5 - 90% (non-condensing)
COO: CHINA
Unit of Measure
Item Weight
2Ships via UPS
NBrand
Team Group
