Raritan 1ph, 230v Ac, 16a (16a Rated); 20 Outlets: 20x C13; Plug: Iec 60309 2p+e 6h 16a (bottom-bottom Feed), 3.7kva; Outlet Metered/switched, Zero U (PX35440V)
Raritan 1ph, 230v Ac, 16a (16a Rated); 20 Outlets: 20x C13; Plug: Iec 60309 2p+e 6h 16a (bottom-bottom Feed), 3.7kva; Outlet Metered/switched, Zero U (PX35440V)
-
1PH, 230V AC, 16A (16A rated); 20 outlets: 20x C13; plug: IEC 60309 2P+E 6h 16A (Bottom-bottom feed), 3.7kVA; Outlet Metered/Switched, Zero U
-
Special order arrives within 3-7 weeks.
Product Description
1PH, 230V AC, 16A (16A rated); 20 outlets: 20x C13; plug: IEC 60309 2P+E 6h 16A (Bottom-bottom feed), 3.7kVA; Outlet Metered/Switched, Zero U vertical PDU, SecureLock ready, high resolution color display with field replaceable controller, Ethernet, serial
Product Specs
Manufacturer
RaritanCategories
Raritan Computer AccessoriesRaritan Power DevicesRaritan Computer Power Distribution UnitsManufacturer Stock No.
PX3-5440VMPN
RRTPX35440VModel#
PX35440VUNSPSC Code
0Information
Product Description: Raritan Dominion PX PX3-5440V - power distribution unit - 3700 VADevice Type: Power distribution unit - rack-mountable
Cord Length: 10 ft
Rack Size: 0U
Weight: 7.05 lbs
Input Wiring: 1-phase 3 Wire
Input Voltage: AC 230 V
Output Voltage: AC 230 V
Power Capacity: 3700 VA
Power Capacity Details: 3.2 kVA at 200 V, 3.8 kVA at 240 V
Input Connectors: 1 x power IEC 60309 16A
Output connectors: 20 x power IEC 60320 C13 - 230 V 10 A
Networking: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP
Color: Black powder coat
Dimensions (WxDxH): 2 in x 2.6 in x 51.1 in
Manufacturer Warranty: 2-year warranty
Device Type: Power distribution unit - rack-mountable
Height (Rack Units): 0U
Cord Length: 10 ft
Color: Black powder coat
Input Voltage: AC 230 V
Input Voltage Range: AC 200 - 240 V
Input Wiring: 1-phase 3 Wire
Frequency Required: 50/60 Hz
Input Connectors: 1 x power IEC 60309 16A
Power Output Connectors Details: 20 x power IEC 60320 C13 - 230 V 10 A
Output Voltage: AC 230 V
Max Electric Current: 16 A
Power Capacity: 3700 VA
Power Capacity Details: 3.2 kVA at 200 V, 3.8 kVA at 240 V
Remote Management Interface: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP
Interfaces: 1 x cascading - RJ-45 ¦ 2 x monitoring - RJ-45 ¦ 1 x RS-232 - RJ-45 ¦ 2 x USB - 4 pin USB Type A ¦ 1 x USB - 4 pin USB Type B ¦ 1 x management (Fast Ethernet) - RJ-45 ¦ 1 x management (Gigabit Ethernet) - RJ-45
Cables Included: Power cable 10 ft
Features: Splash-resistant, voltage monitoring, current meter, cascadable, active power meter, real power meter, energy meter, power factor meter, Raritan SecureLock Ready
Compliant Standards: ICES-003, RoHS, FCC Part 15 A, IEC 62053-21, ISO 62053-21
Service & Support: Limited warranty - 2 years
Max Operating Temperature: 140 °F
Humidity Range Operating: 85%
Width: 2 in
Depth: 2.6 in
Height: 51.1 in
Weight: 7.05 lbs
Shipping Width: 7.3 in
Shipping Depth: 4.7 in
Shipping Height: 55.4 in
Shipping Weight: 13.23 lbs
COO: TAIWAN / TAIWAN / TAIWAN
TAA compliance: Yes
