HP Aruba 2930m 48g 1-slot Switch (JL321A)
Model: JL321A
HP Aruba 2930m 48g 1-slot Switch (JL321A)
Model: JL321A
-
ARUBA 2930M 48G 1-SLOT SWITCH
-
Special order arrives within 3-7 weeks.
Product Description
Aruba 2930M Switch Series - Dual Core ARM Coretex A9 1016 MHz - 1 GB DDR3 SDRAM - 4 GB eMMC - (44) RJ-45 autosensing 10/100/1000 ports (4) Dual Personality 10/100/1000 BASE-T or 100/1000 Mbps SFP Ports (1) uplink module slot, (1) stacking module slot - 10
Product Specs
Manufacturer
HPManufacturer Stock No.
JL321AMPN
HPEJL321AModel#
JL321AUPC Code
190017071237UNSPSC Code
0Information
Product Description: HPE Aruba 2930M 48G 1-Slot - switch - 48 ports - managed - rack-mountableDevice Type: Switch - 48 ports - L3 - managed - stackable
Enclosure Type: Front to back airflow rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 44 x 10/100/1000 + 4 x combo Gigabit SFP
Performance: Throughput: 112 Mpps ¦ Latency (10 Mbps): 98.5 µs ¦ Latency (100 Mbps): 11.8 µs ¦ Latency (1 Gbps): 3.1 µs ¦ Latency (10 Gbps): 3.4 µs ¦ Stacking bandwidth: 100 Gbps ¦ Switching capacity: 176 Gbps
Capacity: IPv4 routing table entries: 2000 ¦ IPv6 routing table entries: 1000 ¦ RIP routes: 10000 ¦ Static routes: 256 ¦ OSPF routes: 200
MAC Address Table Size: 32768 entries
Jumbo Frame Support: 9220 bytes
Routing Protocol: OSPF, RIP, RIP-1, RIP-2, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLDv2, MLD, CIDR
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI, XRMON
Features: Flow control, DHCP support, BOOTP support, VLAN support, IGMP snooping, DiffServ support, IPv6 support, SNTP support, sFlow, QoS, DHCP server, STP Root Guard, UDLD, MIB, dynamic ARP protection, DHCP protection, GVRP, MVRP, CoS, ToS, ICMP Router Discovery Protocol (IRDP), VXLAN
Compliant Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
Power: AC 120/230 V (50/60 Hz) - power supply not installed
Dimensions (WxDxH): 17.4 in x 12.8 in x 1.7 in
Weight: 10.14 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 48 ports - L3 - managed - stackable
Enclosure Type: Front to back airflow rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 44 x 10/100/1000 + 4 x combo Gigabit SFP
Performance: Throughput: 112 Mpps ¦ Latency (10 Mbps): 98.5 µs ¦ Latency (100 Mbps): 11.8 µs ¦ Latency (1 Gbps): 3.1 µs ¦ Latency (10 Gbps): 3.4 µs ¦ Stacking bandwidth: 100 Gbps ¦ Switching capacity: 176 Gbps
Capacity: IPv4 routing table entries: 2000 ¦ IPv6 routing table entries: 1000 ¦ RIP routes: 10000 ¦ Static routes: 256 ¦ OSPF routes: 200
MAC Address Table Size: 32768 entries
Jumbo Frame Support: 9220 bytes
Routing Protocol: OSPF, RIP, RIP-1, RIP-2, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLDv2, MLD, CIDR
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI, XRMON
Encryption Algorithm: MD5, SSL
Authentication Method: RADIUS, PAP, CHAP, TACACS, TACACS+
Features: Flow control, DHCP support, BOOTP support, VLAN support, IGMP snooping, DiffServ support, IPv6 support, SNTP support, sFlow, QoS, DHCP server, STP Root Guard, UDLD, MIB, dynamic ARP protection, DHCP protection, GVRP, MVRP, CoS, ToS, ICMP Router Discovery Protocol (IRDP), VXLAN
Compliant Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
Processor: 1 x ARM Cortex-A9: 1.016 GHz
RAM: 1 GB DDR3 SDRAM
Flash Memory: 4 GB
Interfaces: 44 x 1000Base-T RJ-45 ¦ 4 x Gigabit LAN ¦ 1 x serial (console) RJ-45 ¦ 1 x USB Type B ¦ 1 x management RJ-45
Expansion Slots: 1 (total) / 1 (free) x Stacking Module slot ¦ 1 (total) / 1 (free) x expansion slot
Power Device: Internal power supply (not installed)
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50/60 Hz)
80 PLUS Certification: 80 PLUS Silver
Compliant Standards: CISPR 22 Class A, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition, VCCI Class A, IEC 60825-1: 2007, CNS 13438, EN 55024: 2010, EN 55022: 2010, IEC 60950-1: 2005 + A1: 2009 + A2: 2013, EN 60825-1: 2007, FCC CFR47 Part 15 A, EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013
Width: 17.4 in
Depth: 12.8 in
Height: 1.7 in
Weight: 10.14 lbs
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 °F
Max Operating Temperature: 131 °F
Humidity Range Operating: 15 - 95% (non-condensing)
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 90% (non-condensing)
COO: SINGAPORE
TAA compliance: Yes
Unit of Measure
Item Weight
15.1Ships via UPS
YBrand
HP
$32,362.45
$37,267.00
