Cisco Catalyst 9500 32-port 40/100g Only, Essential (C950032QCE=)
Model: C950032QCE
Cisco Catalyst 9500 32-port 40/100g Only, Essential (C950032QCE=)
Model: C950032QCE
-
CATALYST 9500 32-PORT 40/100G ONLY, ESSENTIAL
-
Special order arrives within 3-7 weeks.
Product Description
Catalyst 9500 32-port 40/100G only, Essential
Product Specs
Manufacturer
CiscoManufacturer Stock No.
C9500-32QC-E=MPN
CSCC950032QCEModel#
C950032QCEUNSPSC Code
0Information
Product Description: Cisco Catalyst 9500 - Network Essentials - switch - 32 ports - managed - rack-mountableDevice Type: Switch - 32 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable 1U
Subtype: 40 Gigabit Ethernet
Ports: 32 x 40 Gigabit QSFP
Performance: Switching capacity (full duplex): 3.2 Tbps ¦ Forwarding rate: 1 Bpps
Capacity: Routing table entries: 80000 ¦ Indirect IPv4 routes: 212000 ¦ Host IPv4 routes: 90000 ¦ Indirect IPv6 routes: 212000 ¦ Host IPv6 routes: 90000 ¦ Multicast scale: 32000 ¦ QoS ACL scale: 16000 ¦ Security ACL scale: 270000 ¦ FNF entries: 96000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000
MAC Address Table Size: 64K entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP-1, RIP-2, BGP, EIGRP, IGMP, VRRP, MSDP, policy-based routing (PBR), RIPng
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, NETCONF, RESTCONF
Features: DHCP support, NAT support, IPv6 support, NSF, SSO, CBWFQ, WRED, STP support, MSTP support, QoS, MLD snooping, NSR, Rapid PVST+, RSPAN, MIB, VRF, MLD, 802.1x authentication, integrated Wireshark, EoMPLS, Private VLAN, ZTP, CoAP support, secure boot, SPAN, FHS
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba
Power: AC 120/230 V (50 - 60 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 17.5 in x 18 in x 1.7 in
Weight: 21.85 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 32 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable 1U
Subtype: 40 Gigabit Ethernet
Ports: 32 x 40 Gigabit QSFP
Performance: Switching capacity (full duplex): 3.2 Tbps ¦ Forwarding rate: 1 Bpps
Capacity: Routing table entries: 80000 ¦ Indirect IPv4 routes: 212000 ¦ Host IPv4 routes: 90000 ¦ Indirect IPv6 routes: 212000 ¦ Host IPv6 routes: 90000 ¦ Multicast scale: 32000 ¦ QoS ACL scale: 16000 ¦ Security ACL scale: 270000 ¦ FNF entries: 96000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000
MAC Address Table Size: 64K entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP-1, RIP-2, BGP, EIGRP, IGMP, VRRP, MSDP, policy-based routing (PBR), RIPng
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, NETCONF, RESTCONF
Encryption Algorithm: 256-bit AES
Features: DHCP support, NAT support, IPv6 support, NSF, SSO, CBWFQ, WRED, STP support, MSTP support, QoS, MLD snooping, NSR, Rapid PVST+, RSPAN, MIB, VRF, MLD, 802.1x authentication, integrated Wireshark, EoMPLS, Private VLAN, ZTP, CoAP support, secure boot, SPAN, FHS
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba
Processor: 1: 2.4 GHz
RAM: 16 GB
Flash Memory: 16 GB
Built-in Devices: RFID tag
Status Indicators: Status
Interfaces: 32 x 100Gbit/40Gbit LAN QSFP ¦ 2 x USB 3.0
Power Device: Internal power supply - hot-plug
Installed Qty: 1
Max Supported Qty: 2
Power Redundancy: Optional
Power Redundancy Scheme: 1+1
Power Provided: 650 Watt
Voltage Required: AC 120/230 V (50 - 60 Hz)
MTBF: 307,200 hours
Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
Software Included: Cisco IOS XE 16.8.1
Width: 17.5 in
Depth: 18 in
Height: 1.7 in
Weight: 21.85 lbs
Service & Support: Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 5 - 90% (non-condensing)
Min Storage Temperature: -4 °F
Max Storage Temperature: 149 °F
Humidity Range Storage: 5 - 95% (non-condensing)
COO: Inquire
TAA compliance: Inquire
