StarTech Sfp Fiber To Ethernet Media Converter (IMC100MSFP)
StarTech Sfp Fiber To Ethernet Media Converter (IMC100MSFP)
-
SFP FIBER TO ETHERNET MEDIA CONVERTER
-
In Stock
Product Description
Fiber to Ethernet Media Converter extends networks & converts optical fiber to RJ45 Copper/CAT6 - Industrial Hardened -40 to 75C temp - 100Mbps - Open SFP - 12V-56VDC - Single Mode (SMF) or Multimode Fiber (MMF) - IP-30 Case 2 Year Warranty
Product Specs
Manufacturer
StarTechCategories
StarTech Computer AccessoriesStarTech Networking, Cables & AccessoriesStarTech Range ExtendersManufacturer Stock No.
IMC100MSFPMPN
STAIMC100MSFPModel#
IMC100MSFPUPC Code
065030889667UNSPSC Code
0Information
Product Description: StarTech.com Industrial Fiber to Ethernet Media Converter, 100Mbps SFP to RJ45/Cat6, Singlemode/Multimode Optical Fiber to Copper Network, 12-56V DC, IP-30/ -40 to +75C, Fiber to Ethernet - SFP to RJ45 Converter (IMC100MSFP) - fiber media converter - 10Mb LAN, 100Mb LANDevice Type: Fiber media converter - RJ-45 / SFP (mini-GBIC)
Form Factor: DIN rail mountable
Cabling Type: 100Base-FX, 100Base-TX
Data Transfer Rate: 100 Mbps
Data Link Protocol: 10Mb LAN, 100Mb LAN
Power: AC 18 - 36 V / DC 12 - 56 V
Dimensions (WxDxH): 1.3 in x 2.3 in x 2 in
Weight: 2.87 oz
Manufacturer Warranty: 2-year warranty
Device Type: Fiber media converter
Form Factor: DIN rail mountable
Color: Black
Connectivity Technology: Wired
Cabling Type: 100Base-FX, 100Base-TX
Data Link Protocol: 10Mb LAN, 100Mb LAN
Data Transfer Rate: 100 Mbps
Status Indicators: Port status, active, link
Features: Flow control, auto-uplink (auto MDI/MDI-X), full duplex mode, Back Pressure Support, 2KV Surge protection
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3x
Interfaces: 1 x Ethernet 100Base-TX - RJ-45 female ¦ 1 x Ethernet 100Base-FX - SFP female
Included Accessories: Power terminal block
Mounting Kit: Included
MTBF: 534,482 hours
Compliant Standards: IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, FCC, RoHS, EN 60950-1, WEEE, MSA, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6
Power Device: External power adapter
Voltage Required: AC 18 - 36 V / DC 12 - 56 V
Power Consumption Operational: 1.92 Watt
Width: 1.3 in
Depth: 2.3 in
Height: 2 in
Weight: 2.87 oz
Shipping Width: 6.1 in
Shipping Depth: 4.1 in
Shipping Height: 2.5 in
Shipping Weight: 7.05 oz
Service & Support: Limited warranty - 2 years
Min Operating Temperature: -40 °F
Max Operating Temperature: 167 °F
Humidity Range Operating: 5 - 95% (non-condensing)
COO: TAIWAN
TAA compliance: Yes
Unit of Measure
Item Weight
0.51Ships via UPS
YBrand
StarTech
