StarTech Industrial 6port Gigabit Ethernet Switch (IES1G52UPDIN)
StarTech Industrial 6port Gigabit Ethernet Switch (IES1G52UPDIN)
-
Industrial 6Port Gigabit Ethernet Switch
-
In Stock
Product Description
Industrial 6 Port Gigabit Ethernet Switch - Up to 30W per 4 PoE ports - 75C to -40C hardened 5 RJ-45 ports (4 PoE) + 2 SFP slots MSA IP-30 housing MTBF 500k + hrs Vibration/shock/free fall rated Unmanaged DIN mountable/DIN connector included 2yr warr
Product Specs
Manufacturer
StarTechCategories
StarTech Computer AccessoriesStarTech Networking, Cables & AccessoriesStarTech Network SwitchesManufacturer Stock No.
IES1G52UPDINMPN
STAIES1G52UPDINModel#
IES1G52UPDINUPC Code
065030889582UNSPSC Code
0Information
Product Description: StarTech.com Industrial 6 Port Gigabit Ethernet Switch 4 PoE RJ45 +2 SFP Slots 30W PoE+ 48VDC 10/100/1000 Power Over Ethernet LAN Switch -40C to 75C, DIN Connector/Mountable, Fast Ethernet - High Power PoE Switch (IES1G52UPDIN) - switch - 6 portsDevice Type: Switch - 6 ports
Subtype: Gigabit Ethernet
Ports: 1 x 10/100/1000 + 4 x 10/100/1000 (PoE+) + 2 x SFP
Power Over Ethernet (PoE): PoE+
PoE Budget: 120 W
Performance: Switching fabric speed: 12 Gbps
Jumbo Frame Support: 9KB
Features: Flow control, full duplex mode, 1MB packet buffer, 2KV ESD Protector, Media Dependent Interface Crossover (MDI-X)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Power: DC 48 - 56 V
Dimensions (WxDxH): 4.1 in x 5.6 in x 1.4 in
Weight: 17.35 oz
Color: Black
Manufacturer Warranty: 2-year warranty
Device Type: Switch - 6 ports
Enclosure Type: DIN rail mountable
Subtype: Gigabit Ethernet
Ports: 1 x 10/100/1000 + 4 x 10/100/1000 (PoE+) + 2 x SFP
Power Over Ethernet (PoE): PoE+
PoE Budget: 120 W
Performance: Switching fabric speed: 12 Gbps
Jumbo Frame Support: 9KB
Features: Flow control, full duplex mode, 1MB packet buffer, 2KV ESD Protector, Media Dependent Interface Crossover (MDI-X)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Status Indicators: Power, PoE, SFP, link
Interfaces: 1 x 1000Base-T RJ-45 ¦ 4 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 2 x SFP ¦ 1 x terminal block
Voltage Required: DC 48 - 56 V
Power Consumption Operational: 126 Watt
Color: Black
Included Accessories: Terminal block connector, mounting kit
MTBF: 525,058 hours
Compliant Standards: IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, UL 60950-1, EN 60950-1, MSA, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6
Width: 4.1 in
Depth: 5.6 in
Height: 1.4 in
Weight: 17.35 oz
Shipping Width: 8.3 in
Shipping Depth: 6.4 in
Shipping Height: 2.5 in
Shipping Weight: 24.69 oz
Service & Support: Limited warranty - 2 years
Min Operating Temperature: -40 °F
Max Operating Temperature: 167 °F
Humidity Range Operating: 5 - 95% (non-condensing)
Min Storage Temperature: -40 °F
Max Storage Temperature: 176 °F
COO: TAIWAN
TAA compliance: Yes
Unit of Measure
Item Weight
1.86Ships via UPS
YBrand
StarTech
$28.92
$35.86
