Raritan 3ph,208v,60a,(12)c19,iec60309 (PX35325RV2)
Raritan 3ph,208v,60a,(12)c19,iec60309 (PX35325RV2)
-
3PH,208V,60A,(12)C19,IEC60309
-
Special order arrives within 3-7 weeks.
Product Description
3PH, 208V AC, 60A (48A/PH rated); 12 outlets: 12x C19; plug: IEC 60309 3P+E 9h 60A (Delta Rear feed), 17.3kVA; Outlet Metered/Switched, 2U horizontal PDU, SecureLock ready, V2 Outlet Sequence
Product Specs
Manufacturer
RaritanCategories
Raritan Computer AccessoriesRaritan Power DevicesRaritan Computer Power Distribution UnitsManufacturer Stock No.
PX3-5325R-V2MPN
RRTPX35325RV2Model#
PX35325RV2UNSPSC Code
0Information
Product Description: Raritan Dominion PX PX3-5325R-V2 - power distribution unit - 17300 VADevice Type: Power distribution unit - rack-mountable
Cord Length: 10 ft
Rack Size: 2U
Weight: 29.76 lbs
Input Wiring: 3-phase delta
Input Voltage: AC 208 V
Output Voltage: AC 208 V
Power Capacity: 17300 VA
Power Capacity Details: 17.3 kVA at 208 V, 20 kVA at 240 V
Input Connectors: 1 x power IEC 60309 3P+E
Output connectors: 12 x power IEC 60320 C19 16 A
Networking: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP
Color: Black powder coat
Dimensions (WxDxH): 17.3 in x 11.5 in x 3.5 in
Manufacturer Warranty: 2-year warranty
Device Type: Power distribution unit - rack-mountable
Height (Rack Units): 2U
Cord Length: 10 ft
Color: Black powder coat
Input Voltage: AC 208 V
Input Voltage Range: AC 208 - 240 V
Input Wiring: 3-phase delta
Frequency Required: 50/60 Hz
Input Connectors: 1 x power IEC 60309 3P+E
Power Output Connectors Details: 12 x power IEC 60320 C19 16 A
Output Voltage: AC 208 V
Max Electric Current: 48 A
Power Capacity: 17300 VA
Power Capacity Details: 17.3 kVA at 208 V, 20 kVA at 240 V
Circuit Protection: Circuit breaker
Remote Management Interface: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP
Interfaces: 1 x Gigabit LAN - RJ-45 ¦ 1 x management (Fast Ethernet) - RJ-45 ¦ 1 x monitoring - RJ-45 ¦ 1 x monitoring - RJ-12 ¦ 1 x management (RS-232) - RJ-45 ¦ 1 x USB - 4 pin USB Type B ¦ 2 x USB - 4 pin USB Type A
Cables Included: Power cable - integrated - 10 ft
Features: LCD display, voltage monitoring, current meter, overload protection, cascadable, active power meter, real power meter, energy meter, power factor meter, Raritan SecureLock Ready, watertight plug, remote outlet switching, metering per input line, metering per branch circuit breaker, metering per output receptacle
Compliant Standards: UL, ICES-003, RoHS, FCC Part 15 A, IEC 62053-21, ISO 62053-21
Service & Support: Limited warranty - 2 years
Max Operating Temperature: 140 °F
Humidity Range Operating: 85%
Width: 17.3 in
Depth: 11.5 in
Height: 3.5 in
Weight: 29.76 lbs
Shipping Width: 22 in
Shipping Depth: 21.7 in
Shipping Height: 11.2 in
Shipping Weight: 36.38 lbs
COO: TAIWAN / TAIWAN / TAIWAN
TAA compliance: Yes
