Raritan 3ph,208v,24a,24xc13,nema (PX35520RE2)
Raritan 3ph,208v,24a,24xc13,nema (PX35520RE2)
-
3PH,208V,24A,24xC13,NEMA
-
Special order arrives within 3-7 weeks.
Product Description
3PH,208V,24A,24xC13,NEMA L21-30P,8.6kVA,2U
Product Specs
Manufacturer
RaritanCategories
Raritan Computer AccessoriesRaritan Power DevicesRaritan Computer Power Distribution UnitsManufacturer Stock No.
PX3-5520R-E2MPN
RRTPX35520RE2Model#
PX35520RE2UNSPSC Code
0Information
Product Description: Raritan PX intelligent PX3-5520R-E2 - power distribution unit - 8600 VADevice Type: Power distribution unit - rack-mountable
Cord Length: 10 ft
Rack Size: 2U
Weight: 18.08 lbs
Input Wiring: 3-phase delta
Input Voltage: AC 208 V
Output Voltage: AC 208 V
Power Capacity: 8600 VA
Input Connectors: 1 x power NEMA L21-30P
Output connectors: 24 x power IEC 60320 C13 - 208 V 12 A
Networking: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Color: Black powder coat
Dimensions (WxDxH): 17.3 in x 11.5 in x 3.5 in
Manufacturer Warranty: 2-year warranty
Device Type: Power distribution unit - rack-mountable
Height (Rack Units): 2U
Cord Length: 10 ft
Color: Black powder coat
Input Voltage: AC 208 V
Input Voltage Range: AC 190 - 208 V
Input Wiring: 3-phase delta
Frequency Required: 50/60 Hz
Input Connectors: 1 x power NEMA L21-30P
Power Output Connectors Details: 24 x power IEC 60320 C13 - 208 V 12 A
Output Voltage: AC 208 V
Max Electric Current: 24 A
Power Capacity: 8600 VA
Circuit Protection: Circuit breaker
Remote Management Interface: RS-232, Ethernet 10/100/1000
Remote Management Protocol: SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Interfaces: 1 x LAN - RJ-45 ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x monitoring - RJ-12 ¦ 1 x monitoring - RJ-45 ¦ 2 x USB - 4 pin USB Type A ¦ 1 x USB - 4 pin USB Type B
Cables Included: Power cable - integrated - 10 ft
Rack Mounting Kit: Included
Features: LED display, voltage monitoring, current meter, overload protection, cascadable, active power meter, real power meter, energy meter, power factor meter, Raritan SecureLock Ready, splash-proof plug
Compliant Standards: UL, ICES-003, RoHS, FCC Part 15 A, cULus, IP44
Service & Support: Limited warranty - 2 years
Max Operating Temperature: 140 °F
Humidity Range Operating: 85%
Width: 17.3 in
Depth: 11.5 in
Height: 3.5 in
Weight: 18.08 lbs
Shipping Width: 21.7 in
Shipping Depth: 11.2 in
Shipping Height: 22 in
Shipping Weight: 25.35 lbs
COO: TAIWAN / TAIWAN
TAA compliance: Yes
Unit of Measure
Item Weight
25.3Ships via UPS
