NETGEAR 24-port High-power Poe+ Gigabit (GS524UP100NAS)
NETGEAR 24-port High-power Poe+ Gigabit (GS524UP100NAS)
-
24-Port High-power PoE+ Gigabit
-
In Stock
Product Description
NETGEAR 24-Port High-power PoE+ Gigabit Ethernet Ultra60 PoE++ Unmanaged Switch with 16 ports PoE++ and 8 ports PoE+ and 480W PoE budget, Rackmount or Desktop
Product Specs
Manufacturer
NetgearCategories
Netgear Computer AccessoriesNetgear Networking, Cables & AccessoriesNetgear Network SwitchesManufacturer Stock No.
GS524UP-100NASMPN
NETGS524UP100NASModel#
GS524UP100NASUPC Code
606449149760UNSPSC Code
0Information
Product Description: NETGEAR GS524UP - switch - 24 ports - unmanaged - rack-mountableDevice Type: Switch - 24 ports - unmanaged
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 8 x 10/100/1000 (PoE+) + 16 x 10/100/1000 (PoE++)
Power Over Ethernet (PoE): PoE++
PoE Budget: 480 W
Performance: Non-blocking switching throughput: 48 Gbps ¦ Forwarding rate (1000Mbps): 1448000 packets per second ¦ Latency (64-byte packets): 12 µs
MAC Address Table Size: 8K entries
Jumbo Frame Support: 9216 bytes
Features: Auto-negotiation, auto-uplink (auto MDI/MDI-X), 192KB packet buffer, Class of Service (CoS), metal housing, DiffServ Code Point (DSCP) support, 2 fans, Weighted Round Robin (WRR)
Compliant Standards: IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
Power: AC 100 - 230 V (50/60 Hz)
Dimensions (WxDxH): 15.4 in x 8.7 in x 1.7 in
Weight: 6.83 lbs
Localization: Asia Pacific, North America
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 24 ports - unmanaged
Enclosure Type: Desktop, rack-mountable
Subtype: Gigabit Ethernet
Ports: 8 x 10/100/1000 (PoE+) + 16 x 10/100/1000 (PoE++)
Power Over Ethernet (PoE): PoE++
PoE Budget: 480 W
Performance: Non-blocking switching throughput: 48 Gbps ¦ Forwarding rate (1000Mbps): 1448000 packets per second ¦ Latency (64-byte packets): 12 µs
MAC Address Table Size: 8K entries
Jumbo Frame Support: 9216 bytes
Features: Auto-negotiation, auto-uplink (auto MDI/MDI-X), 192KB packet buffer, Class of Service (CoS), metal housing, DiffServ Code Point (DSCP) support, 2 fans, Weighted Round Robin (WRR)
Compliant Standards: IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
Status Indicators: Power, PoE, link/activity, fan
Interfaces: 24 x 10/100/1000 Base-T RJ-45 16 ports (PoE++)/8 ports (PoE+) - 60 W
Power Device: Internal power supply
Installed Qty: 1
Voltage Required: AC 100 - 230 V (50/60 Hz)
Power Consumption Operational: 578.8 Watt
Power Consumption Stand by: 24.4 Watt
Included Accessories: Rubber feet
Rack Mounting Kit: Included
MTBF: 809853.3 hours
Compliant Standards: Plug and Play, IEC 60950-1, BSMI CNS 14336-1, IEC 62368-1, EN 62368-1 Second Edition, UL 62368-1, EN60950-1 (2nd Edition), AS/NZS 62368.1
Localization: Asia Pacific, North America
Width: 15.4 in
Depth: 8.7 in
Height: 1.7 in
Weight: 6.83 lbs
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 °F
Max Operating Temperature: 122 °F
Humidity Range Operating: 10 - 90% (non-condensing)
Min Storage Temperature: -4 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 10 - 95% (non-condensing)
COO: THAILAND
TAA compliance: No
Unit of Measure
Item Weight
8.5Ships via UPS
YBrand
Netgear
