Lenovo Thinksystem St650 V2 4309y 32gb (7Z74A01QNA)
Model: 7Z74A01QNA
Lenovo Thinksystem St650 V2 4309y 32gb (7Z74A01QNA)
Model: 7Z74A01QNA
-
THINKSYSTEM ST650 V2 4309Y 32GB
-
Special order arrives within 3-7 weeks.
Product Description
ThinkSystem ST650 V2 4309Y 32GB
Product Specs
Manufacturer
LenovoManufacturer Stock No.
7Z74A01QNAMPN
LES7Z74A01QNAModel#
7Z74A01QNAUNSPSC Code
0Information
Product Description: Lenovo ThinkSystem ST650 V2 - tower - Xeon Silver 4309Y 2.8 GHz - 32 GB - no HDDType: Server - tower
Height (Rack Units): 4U
Localization: Region: Canada, United States
Server Scalability: 2-way
Processor: 1 x Intel Xeon Silver (3rd Gen) 4309Y / 2.8 GHz (3.6 GHz) (8-core)
Processor Socket: LGA4189 Socket
Processor Main Features: Intel Turbo Boost Technology 2
Cache Memory: 12 MB L3 cache
Cache Per Processor: 12 MB
RAM: 32 GB (installed) / 2 TB (max) - DDR4 SDRAM - ECC
Storage Controller: SATA
Server Storage Bays: Hot-swap 2.5"
Hard Drive: No HDD
Optical Storage: No optical drive
Graphics Controller: Matrox G200
Video Memory: 16 MB
Networking: GigE, 10 GigE
Power: (50/60 Hz)
Power Redundancy: Optional
OS Provided: No operating system
Dimensions (WxDxH): 6.9 in x 28.9 in x 18.2 in
Weight: 101.92 lbs
Environmental Standards: ENERGY STAR Qualified EPEAT Bronze
Manufacturer Warranty: Limited warranty - 3 years - on-site - response time: next business day
Type: Server
Product Form Factor: Tower - 4U
Built-in Devices: LED panel, 3 x performance fans
Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability: 2-way
Front Accessible Bays Qty: 2
Hot-Swap Bays Qty: 8
Localization: Region: Canada, United States
CPU: Intel Xeon Silver (3rd Gen) 4309Y
Clock Speed: 2.8 GHz
Max Turbo Speed: 3.6 GHz
Number of Cores: 8-core
CPU Qty: 1
Max CPU Qty: 2
Processor Main Features: Intel Turbo Boost Technology 2
CPU Socket: LGA4189 Socket
Chipset Type: Intel C621A
Installed Size: L3 cache - 12 MB
Cache Per Processor: 12 MB
Installed Size: 32 GB / 2 TB (max)
Technology: DDR4 SDRAM - ECC
Effective Memory Speed: 2667 MHz
Rated Memory Speed: 3200 MHz
Form Factor: DIMM 288-pin
Slots: 32 (total) / 31 (empty)
Features: Registered, Memory Mirroring, 8-channel memory architecture, TruDDR4, slots 17 - 32 are available in two-processor configuration only
Configuration Features: 1 x 32 GB
RAM Supported: 4 TB 3DS registered ¦ 2 TB registered ¦ 5 TB Persistent Memory
Type: No HDD
Type: 1 x SATA
Channel Qty: 12
RAID Level: RAID 0, RAID 1, RAID 5, RAID 10, JBOD
Type: No optical drive
Monitor Type: None.
Graphics Processor: Matrox G200
Video Memory: 16 MB
Video Interfaces: VGA
Ethernet Ports: 2 x 10 Gigabit Ethernet
Ethernet Controller: Broadcom BCM57416
Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller: XClarity Controller (XCC) Enterprise
Features: PXE support
Bays: 2 (total) / 2 (free) x external 5.25" x 1/2H ¦ 8 (total) / 8 (free) x hot-swap 2.5"
Slots: 2 PCIe 4.0 x16 - full-length, full-height ¦ 1 PCIe 4.0 x8 - full-length, full-height (x4 mode) ¦ 1 PCIe 4.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - full-length, full-height (2 processors must be installed) ¦ 2 (total) / 2 (free) x PCIe 4.0 x16 - full-length, full-height (2 processors must be installed) ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - full-length, full-height (2 processors must be installed)
Interfaces: 6 x USB 3.1 Gen 1 (1 front, 4 rear, 1 internal) ¦ 1 x USB 2.0 (1 in front) ¦ 1 x VGA ¦ 1 x serial ¦ 1 x management (Gigabit Ethernet) - RJ-45 ¦ 2 x LAN (10Gigabit Ethernet) - RJ-45
Theft/Intrusion Protection: Chassis intrusion switch
Compliant Standards: BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, CB, CCC, FCC Part 15 A, GREENGUARD, GB 17625.1, CECP, VCCI Class A, EN 50581, GB 4943.1, KN35, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, EN 55035, CISPR 35, CELP, HJ 2507-2011, TP EAC 037/2016, AS/NZS 62368.1, UKCA, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135
Device Type: Power supply - hot-plug
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (with optional power supply)
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: AC 100-127/200-240 V (50/60 Hz)
Power Provided: 750 Watt
80 PLUS Certification: 80 PLUS Platinum
OS Provided: No operating system
EPEAT Compliant: EPEAT Bronze
ENERGY STAR Certified: Yes
ENERGY STAR Version: 3.0
Service & Support: Limited warranty - 3 years - on-site - response time: next business day
Width: 6.9 in
Depth: 28.9 in
Height: 18.2 in
Weight: 101.92 lbs
Shipping Width: 23.5 in
Shipping Depth: 39.2 in
Shipping Height: 14.7 in
COO: MEXICO
TAA compliance: Yes
