Lenovo Qlogic 16gb Fc Dual-port Hba (01CV760)
Model: 01CV760
Lenovo Qlogic 16gb Fc Dual-port Hba (01CV760)
Model: 01CV760
-
QLOGIC 16GB FC DUAL-PORT HBA
-
Special order arrives within 3-7 weeks.
Product Description
QLogic 16Gb FC Dual-port HBA
Product Specs
Manufacturer
LenovoManufacturer Stock No.
01CV760MPN
LES01CV760Model#
01CV760UPC Code
889488417322UNSPSC Code
0Information
Product Description: QLogic 16Gb FC Dual-Port HBA (Enhanced Gen 5) - host bus adapter - PCIe 3.0 x8 - 16Gb Fibre Channel x 2Device Type: Host bus adapter
Form Factor: Plug-in card - low profile
Interface (Bus) Type: PCI Express 3.0 x8
Ports: 16Gb Fibre Channel x 2
Dimensions (WxDxH): 6.6 in x 2.7 in
Data Link Protocol: 4Gb Fibre Channel, 8Gb Fibre Channel, 16Gb Fibre Channel
Data Transfer Rate: 14.025 Gbps
Performance: Maximum IOPS: 1300000
System Requirements: Microsoft Windows Server 2012, Red Hat Enterprise Linux 6 x64 Edition, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 12, VMware vSphere 5.5 update 2, SuSE Linux Enterprise Server 12 SP1, SuSE Linux Enterprise Server 11 SP4 for AMD64/EM64T, SuSE Linux Enterprise Server 11 SP3 for AMD64/EM64T, VMware vSphere 5.5 update 3, VMware vSphere 6.0, VMware vSphere 6.0 update 1, VMware vSphere 6.0 update 2
Manufacturer Warranty: 1-year warranty
Designed For: NeXtScale nx360 M5; System x3500 M5; x3550 M5; x3650 M5; x3750 M4; x3850 X6; x3950 X6; ThinkSystem SR250 7Y51; SR530 7X08; SR590; SR630 7X02; SR630 V2 7Z71; SR645 7D2X; SR650 7X06; SR650 V2 7D15, 7Z73; SR665 7D2V, 7D2W; SR850 V2 7D32; ST550 7X10; ST650 V2 7Z74, 7Z75
Device Type: Host bus adapter
Form Factor: Plug-in card - low profile
Interface (Bus) Type: PCI Express 3.0 x8
Ports: 16Gb Fibre Channel x 2
Connectivity Technology: Wired
Data Link Protocol: 4Gb Fibre Channel, 8Gb Fibre Channel, 16Gb Fibre Channel
Fibre Channel: FC-GS-2, FC-GS-3, FC-Tape, FCP-2, FC-PI-5, SCSI-FCP
Data Transfer Rate: 14.025 Gbps
Performance: Maximum IOPS: 1300000
Features: QoS, FEC, MSI-X, FA-WWN, F-BLD, LCB
Interfaces: 2 x 16Gb Fibre Channel
Included Accessories: Low-profile bracket, full-height bracket, 16 Gb shortwave Fibre Channel SFP+ LC transceiver
Compliant Standards: ICES-003 Class A, UL 60950-1 Second Edition, FCC Part 15 A, BSMI Class A, KCC Class A, VCCI Class A, EN55022: 2010 Class A, AS/NZS CISPR22: 2009+A1 Class A, EN 55024: 2010, CAN/CSA C22.2 No. 60950-1-07 Second Edition 2011-12, EN60950-1: 2006 +A11+A1+A12 (2nd Edition)
OS Required: Microsoft Windows Server 2012, Red Hat Enterprise Linux 6 x64 Edition, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 12, VMware vSphere 5.5 update 2, SuSE Linux Enterprise Server 12 SP1, SuSE Linux Enterprise Server 11 SP4 for AMD64/EM64T, SuSE Linux Enterprise Server 11 SP3 for AMD64/EM64T, VMware vSphere 5.5 update 3, VMware vSphere 6.0, VMware vSphere 6.0 update 1, VMware vSphere 6.0 update 2
Depth: 6.6 in
Height: 2.7 in
Service & Support: Limited warranty - 1 year
Min Operating Temperature: 32 °F
Max Operating Temperature: 131 °F
Humidity Range Operating: 10 - 90% (non-condensing)
Designed For: Lenovo NeXtScale nx360 M5 ¦ Lenovo System x3500 M5 ¦ Lenovo System x3550 M5 ¦ Lenovo System x3650 M5 ¦ Lenovo System x3750 M4 ¦ Lenovo System x3850 X6 ¦ Lenovo System x3950 X6 ¦ Lenovo ThinkSystem SR250 7Y51 ¦ Lenovo ThinkSystem SR530 7X08 ¦ Lenovo ThinkSystem SR590 ¦ Lenovo ThinkSystem SR630 7X02 ¦ Lenovo ThinkSystem SR630 V2 7Z71 ¦ Lenovo ThinkSystem SR645 7D2X ¦ Lenovo ThinkSystem SR650 7X06 ¦ Lenovo ThinkSystem SR650 V2 7D15, 7Z73 ¦ Lenovo ThinkSystem SR665 7D2V, 7D2W ¦ Lenovo ThinkSystem SR850 V2 7D32 ¦ Lenovo ThinkSystem ST550 7X10 ¦ Lenovo ThinkSystem ST650 V2 7Z74, 7Z75
COO: MEXICO
TAA compliance: Yes
Unit of Measure
Item Weight
0.9Ships via UPS
YBrand
Lenovo
$1,591.54
$1,909.85
$1,196.53
$1,435.84
$2,368.83
$2,842.60
$4,292.95
$5,151.54
$8,192.15
$9,830.58
$6,803.23
$8,163.88
$189.75
$227.70
$54.31
$65.17
