Lenovo Db610s 24x16gb Sfp E Bundle (1yr) (6559F1A)
Model: 6559F1A
Lenovo Db610s 24x16gb Sfp E Bundle (1yr) (6559F1A)
Model: 6559F1A
-
DB610S 24x16Gb SFP E Bundle (1yr)
-
Special order arrives within 3-7 weeks.
Product Description
DB610S 24x16Gb SFP E Bundle (1yr)
Product Specs
Manufacturer
LenovoCategories
Lenovo Computer AccessoriesLenovo Networking, Cables & AccessoriesLenovo Network SwitchesManufacturer Stock No.
6559F1AMPN
LES6559F1AModel#
6559F1AUPC Code
889488473281UNSPSC Code
0Information
Product Description: Lenovo ThinkSystem DB610S - switch - 24 ports - managed - rack-mountable - with Enterprise SoftwareDevice Type: Switch - 24 ports - managed - with Enterprise Software
Enclosure Type: Rack-mountable 1U
Subtype: Fibre Channel
Ports: 24 x 32Gb Fibre Channel SFP+
Performance: Aggregate throughput: 768 Gbps ¦ Switching latency: 0.9 µs
Capacity: Maximum frame size: 2112 byte ¦ Frame buffers: 2000
Remote Management Protocol: SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, SMI-S, SSH, SSH-2, CLI, SCP, SFTP
Features: Syslog support, IPv6 support, IP address filtering, firmware upgradable, Full Fabric, event log, ACL support, QoS, enviromental monitoring, FEC, RSCN support, Extended Fabric, ISL Trunking, FSPF, FDMI, RBAC, DPS, DLS, RCS, SNS, FCAP, POST, NTP, flow mirroring, DFP, 3+1 redundant fans, TIZ, RRD
Power: AC 120/230 V (50/60 Hz)
Dimensions (WxDxH): 16.9 in x 12.1 in x 1.7 in
Weight: 9.26 lbs
Manufacturer Warranty: 1-year warranty
Device Type: Switch - 24 ports - managed - with Enterprise Software
Enclosure Type: Desktop, rack-mountable 1U
Subtype: Fibre Channel
Ports: 24 x 32Gb Fibre Channel SFP+
Performance: Aggregate throughput: 768 Gbps ¦ Switching latency: 0.9 µs
Capacity: Maximum frame size: 2112 byte ¦ Frame buffers: 2000
Fibre Channel: FC-DA, FC-FS, FC-GS-4, FC-SB, FC-SB-2, FC-SB-3, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-4, FC-BB-2, FCP, FCP-2, FC-BB-5, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FCP-3, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5, FC-BB-4, FC-IFR, FC-PI-5, FC-LS-2, FC-SP-2, FC-SB-4, FC-DA-2, FC-MI-3, FC-BB-6, FC-SB-5, FC-FS-4, FC-SW-6, FC-GS-7, FC-PI-6, FC-GS-8, FC-LS-3, FC-SB-6, FC-SW-7, MIB-FA
Remote Management Protocol: SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, SMI-S, SSH, SSH-2, CLI, SCP, SFTP
Encryption Algorithm: SSL
Authentication Method: RADIUS, TACACS+, LDAP, FCAP
Features: Syslog support, IPv6 support, IP address filtering, firmware upgradable, Full Fabric, event log, ACL support, QoS, enviromental monitoring, FEC, RSCN support, Extended Fabric, ISL Trunking, FSPF, FDMI, RBAC, DPS, DLS, RCS, SNS, FCAP, POST, NTP, flow mirroring, DFP, 3+1 redundant fans, TIZ, RRD
Interfaces: 24 x 4/8/16/32Gb Fibre Channel SFP+ ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x serial RJ-45 ¦ 1 x USB
Power Device: Internal power supply
Power Provided: 150 Watt
Voltage Required: AC 120/230 V (50/60 Hz)
Included Accessories: 24 x 16Gb Fibre Channel SFP+ Short Wave Transceiver
Cables Included: 1 x DB-9 to RJ-45 adapter
Rack Mounting Kit: Included
Compliant Standards: VCCI, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC Part 15 B, UL 60950-1, IEC 60950-1, EN 60950-1, GB 9254, CNS 13438, KN32, KN35, CNS 14336-1, EN 55032
Software Included: ISL Trunking, Extended Fabric
Width: 16.9 in
Depth: 12.1 in
Height: 1.7 in
Weight: 9.26 lbs
Service & Support: Limited warranty - replacement - 1 year - response time: next business day ¦ New releases update - 3 years ¦ Technical support - 3 years
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 10 - 85% (non-condensing)
Min Storage Temperature: -13 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 10 - 90% (non-condensing)
COO: Inquire
TAA compliance: Inquire
