Lenovo 3.5 S4520 960gb Ri Sata Hs (4XB7A17120)
Model: 4XB7A17120
Lenovo 3.5 S4520 960gb Ri Sata Hs (4XB7A17120)
Model: 4XB7A17120
-
3.5 S4520 960GB RI SATA HS
-
Out Of Stock
Product Description
S4520 - 960GB - SATA 6 Gb/s - 3.5 - 6Gbps - one-year
Product Specs
Manufacturer
LenovoManufacturer Stock No.
4XB7A17120MPN
LES4XB7A17120Model#
4XB7A17120UPC Code
889488589203UNSPSC Code
0Information
Product Description: Lenovo ThinkSystem S4520 - SSD - Read Intensive - 960 GB - SATA 6Gb/sType: Solid state drive - hot-swap
Capacity: 960 GB
Hardware Encryption: Yes
Encryption Algorithm: 256-bit AES
NAND Flash Memory Type: 3D triple-level cell (TLC)
Form Factor: 3.5"
Interface: SATA 6Gb/s
Data Transfer Rate: 600 MBps
Drive Class: Read Intensive
Features: Thermal throttling, End-to-end data protection, 3D NAND Technology, Standard Endurance Technology (SET), Enhanced Power Loss Protection, S.M.A.R.T., 256-bit AES
Dimensions (WxDxH): 2.8 in x 3.9 in x 0.3 in
Weight: 2.47 oz
Manufacturer Warranty: 1-year warranty
Designed For: ThinkAgile VX5530 Appliance 7Z63 (3.5"); ThinkSystem SR250 7Y51 (3.5"), 7Y52 (3.5"); SR530 7X07 (3.5"), 7X08 (3.5"); SR550 7X03 (3.5"), 7X04 (3.5"); SR570 7Y02 (3.5"), 7Y03 (3.5"); SR590 7X98 (3.5"), 7X99 (3.5"); SR630 7X01 (3.5"), 7X02 (3.5"); SR635 7Y98 (3.5"), 7Y99 (3.5"); SR645 7D2X (3.5"), 7D2Y (3.5"); SR650 7X05 (3.5"), 7X06 (3.5"); SR650 V2 7D15 (3.5"); SR655 7Y00 (3.5"), 7Z01 (3.5"); SR665 7D2V (3.5"), 7D2W (3.5"); ST250 7Y45 (3.5"), 7Y46 (3.5"); ST550 7X09 (3.5"), 7X10 (3.5")
Device Type: Solid state drive - hot-swap
Capacity: 960 GB
Hardware Encryption: Yes
Encryption Algorithm: 256-bit AES
NAND Flash Memory Type: 3D triple-level cell (TLC)
Form Factor: 3.5"
Interface: SATA 6Gb/s
Features: Thermal throttling, End-to-end data protection, 3D NAND Technology, Standard Endurance Technology (SET), Enhanced Power Loss Protection, S.M.A.R.T., 256-bit AES
Width: 2.8 in
Depth: 3.9 in
Height: 0.3 in
Weight: 2.47 oz
Drive Writes Per Day (DWPD): 3
SSD Endurance: 5.3 PB
Drive Class: Read Intensive
Drive Transfer Rate: 600 MBps (external)
Internal Data Rate: 550 MBps (read) / 510 MBps (write)
4KB Random Read: 85000 IOPS
4KB Random Write: 44000 IOPS
Average Latency: 36 µs
MTBF: 2,000,000 hours
Non-Recoverable Errors: 1 per 10^17
Interfaces: 1 x SATA 6 Gb/s
Compatible Bay: 3.5"
Power Consumption: 2.3 Watt (typical)
Compliant Standards: VCCI, ICES-003, BSMI CNS 13438, CSA C22.2 No. 60950-1-07 Second Edition, RoHS 2011/65/EU, EN55022: 2006, AS/NZS CISPR22: 2009+A1: 2010, WEEE 2012/19/EU, EMC 2014/30/EU, FCC Part 15 Class B, LVD 2014/35/EU, EN 55032: 2012, UL 60950 Second Edition, Morocco, KCC Article 11.1, AS/NZS CISPR 32: 2015, EN 55035: 2017, UL/CSA/EN 62368-1, FCC Title 47, China EFUP
Service & Support: Limited warranty - replacement - 1 year
Min Operating Temperature: 32 °F
Max Operating Temperature: 158 °F
Humidity Range Operating: 5 - 95% (non-condensing)
Shock Tolerance (operating): 1000 g @ 0.5 ms
Shock Tolerance (non-operating): 1000 g @ 0.5 ms
Vibration Tolerance (operating): 2.17 g @ 5-700 Hz
Vibration Tolerance (non-operating): 3.13 g @ 5-800 Hz
Designed For: Lenovo ThinkAgile VX5530 Appliance 7Z63 (3.5") ¦ Lenovo ThinkSystem SR250 7Y51 (3.5"), 7Y52 (3.5") ¦ Lenovo ThinkSystem SR530 7X07 (3.5"), 7X08 (3.5") ¦ Lenovo ThinkSystem SR550 7X03 (3.5"), 7X04 (3.5") ¦ Lenovo ThinkSystem SR570 7Y02 (3.5"), 7Y03 (3.5") ¦ Lenovo ThinkSystem SR590 7X98 (3.5"), 7X99 (3.5") ¦ Lenovo ThinkSystem SR630 7X01 (3.5"), 7X02 (3.5") ¦ Lenovo ThinkSystem SR635 7Y98 (3.5"), 7Y99 (3.5") ¦ Lenovo ThinkSystem SR645 7D2X (3.5"), 7D2Y (3.5") ¦ Lenovo ThinkSystem SR650 7X05 (3.5"), 7X06 (3.5") ¦ Lenovo ThinkSystem SR650 V2 7D15 (3.5") ¦ Lenovo ThinkSystem SR655 7Y00 (3.5"), 7Z01 (3.5") ¦ Lenovo ThinkSystem SR665 7D2V (3.5"), 7D2W (3.5") ¦ Lenovo ThinkSystem ST250 7Y45 (3.5"), 7Y46 (3.5") ¦ Lenovo ThinkSystem ST550 7X09 (3.5"), 7X10 (3.5")
COO: Inquire
TAA compliance: Inquire
