INTEL E810-XXVDA2, OCP3.0 - INTERLOCK
-
Out Of Stock
Product Description
Gigabit Ethernet - SFP28 - PCI Express x4 - Gigabit Ethernet
Product Specs
Manufacturer
IntelManufacturer Stock No.
E810XXVDA2OCP3LMPN
INTE810XXVDA2OCP3LModel#
E810XXVDA2OCP3LUPC Code
007358584522UNSPSC Code
0Information
Product Description: Intel Ethernet Network Adapter E810-XXVDA2 - network adapter - Open Compute Project (OCP) 4.0 - 10/25 Gigabit SFP28 x 2Device Type: Network adapter
Form Factor: Plug-in card
Interface (Bus) Type: Open Compute Project (OCP) 4.0
PCI Specification Revision: PCIe 4.0
Ports: 10/25 Gigabit SFP28 x 2
Dimensions (WxDxH): 3 in x 4.5 in
Data Link Protocol: 10GbE, 25GbE
Capacity: Tx queues: 2048 ¦ Rx queues: 2048 ¦ Programmable TCAM entries: 8000 ¦ Single Root I/O Virtualization (SR-IOV) virtual functions: up to 256 ¦ VLAN tags: up to 4096 ¦ Tx Doorbell (DB) queues: 256 ¦ Tx Completion queues: 512 ¦ Concurrent non-posted requests: 256
Network / Transport Protocol: TCP/IP, UDP/IP, iSCSI, iWARP, NFS
Compliant Standards: IEEE 802.1p, IEEE 1588v2, IEEE 802.3by, IEEE 1588v1
Manufacturer Warranty: Limited lifetime warranty
Device Type: Network adapter
Form Factor: Plug-in card
Interface (Bus) Type: Open Compute Project (OCP) 4.0
PCI Specification Revision: PCIe 4.0
Ports: 10/25 Gigabit SFP28 x 2
Connectivity Technology: Wired
Data Link Protocol: 10 Gigabit Ethernet, 25 Gigabit Ethernet
Capacity: Tx queues: 2048 ¦ Rx queues: 2048 ¦ Programmable TCAM entries: 8000 ¦ Single Root I/O Virtualization (SR-IOV) virtual functions: up to 256 ¦ VLAN tags: up to 4096 ¦ Tx Doorbell (DB) queues: 256 ¦ Tx Completion queues: 512 ¦ Concurrent non-posted requests: 256
Network / Transport Protocol: TCP/IP, UDP/IP, iSCSI, iWARP, NFS
Remote Management Protocol: SNMP, RMON
Status Indicators: Link/activity/speed
Features: VLAN support, WFQ, RDMA support, VMDq, UEFI support, SR-IOV, PTP, VT-c, DDIO Technology, RoCE v2, Intel Flow Director, FPP, intelligent offloads, Advanced Packet Filtering, DPDK, VLAN Tagging, MCTP over SMBus, VMLB, On-chip QoS and Traffic Management, hardware root of trust, DDP, ADQ, ACL support, ZTNA
Compliant Standards: IEEE 802.1p, IEEE 1588v2, IEEE 802.3by, IEEE 1588v1
Interfaces: 2 x 10Gb Ethernet/25Gb Ethernet - SFP28
Compliant Standards: FCC Class A certified, UL, VCCI, BSMI, KCC, RCM, Directive 2015/863/EU, RoHS II 2011/65/EU
Width: 3 in
Depth: 4.5 in
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 °F
Max Operating Temperature: 149 °F
COO: MALAYSIA
TAA compliance: No
Unit of Measure
Item Weight
0.3Ships via UPS
YBrand
Intel
$1,129.81
$1,355.78
