HP e Dl380 Gen10 4214r 1p 32g Nc 8sff Svr (P24842B21)
Model: P24842B21
HP e Dl380 Gen10 4214r 1p 32g Nc 8sff Svr (P24842B21)
Model: P24842B21
-
HPE DL380 GEN10 4214R 1P 32G NC 8SFF SVR
-
Out Of Stock
Product Description
HPE ProLiant DL380 Gen10 server - 2U - Intel Xeon 4210R 2.4GHz 10-Core 13.75MB - 32GB RDIMM DDR4 - 1 HPE Smart Array P408i-a/2GB with Smart Storage Battery and 1 HPE Smart Array S100i - 1 HPE Ethernet 1Gb 4-port 366FLR FlexibleLOM Adapter (665240-B21) plu
Product Specs
Manufacturer
HPManufacturer Stock No.
P24842-B21MPN
HPEP24842B21Model#
P24842B21UPC Code
190017446394UNSPSC Code
0Information
Product Description: HPE ProLiant DL380 Gen10 Network Choice - rack-mountable - AI Ready - Xeon Silver 4214R 2.4 GHz - 32 GB - no HDDType: Server - rack-mountable AI Ready
Height (Rack Units): 2U
Localization: Region: Worldwide (excluding China, Japan)
Server Scalability: 2-way
Processor: 1 x Intel Xeon Silver 4214R / 2.4 GHz (, up to 3.5 GHz, (12-core)
Processor Socket: FCLGA3647 Socket
Processor Main Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory: 16.5 MB L3 cache
Cache Per Processor: 16.5 MB
RAM: 32 GB (installed) / 1.5 TB (max) - DDR4 SDRAM - Advanced ECC
Storage Controller: RAID (SATA 6Gb/s / SAS 12Gb/s) - PCIe 3.0 x8 (HPE Smart Array P408i-a SR Gen10)
Server Storage Bays: Hot-swap 2.5"
Hard Drive: No HDD
Optical Storage: No optical drive
Video Memory: 16 MB
Networking: 1GbE
Power: AC 120/230 V (50/60 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 17.5 in x 28.8 in x 3.4 in
Weight: 32.54 lbs
Manufacturer Warranty: Limited warranty - parts and labor - 3 years - on-site
Type: Server - AI Ready
Product Form Factor: Rack-mountable - 2U
Server Scalability: 2-way
Hot-Swap Bays Qty: 8
Localization: Region: Worldwide (excluding China, Japan)
CPU: Intel Xeon Silver 4214R
Clock Speed: 2.4 GHz
Max Turbo Speed: 3.5 GHz
Number of Cores: 12-core
CPU Qty: 1
Max CPU Qty: 2
CPU Upgradability: Upgradable
Processor Main Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket: FCLGA3647 Socket
Chipset Type: Intel C621
Installed Size: L3 cache - 16.5 MB
Cache Per Processor: 16.5 MB
Installed Size: 32 GB (installed) / 1.5 TB (max)
Technology: DDR4 SDRAM - Advanced ECC
Effective Memory Speed: 2400 MHz
Rated Memory Speed: 2933 MHz
Form Factor: DIMM 288-pin
Slots: 24 (total) / 23 (empty)
Features: Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features: 1 x 32 GB
RAM Supported: 3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC ¦ 192 GB Non-Volatile - ECC ¦ 6 TB - HPE Persistent Memory - Optane DC Persistent
Type: No HDD
Type: 1 x RAID - PCIe 3.0 x8
Controller Interface Type: SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name: HPE Smart Array P408i-a SR Gen10
Channel Qty: 8
RAID Level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size: 2 GB
Type: No optical drive
Monitor Type: None.
Video Memory: 16 MB
Video Interfaces: VGA
Ethernet Ports: 4 x Gigabit Ethernet
Ethernet Controller: HPE 366FLR
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 5
Bays: 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots: 1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 0 (free) x FlexibleLOM
Interfaces: 3 x USB 3.0 (1 front, 2 rear) ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x HPE iLO (service port)
Included Accessories: Cable management arm, 4 standard fans, SFF Easy install rails
Compliant Standards: WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Device Type: Power supply - hot-plug
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (with optional power supply)
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50/60 Hz)
Power Provided: 800 Watt
80 PLUS Certification: 80 PLUS Platinum
Service & Support: Limited warranty - parts and labor - 3 years - on-site
Width: 17.5 in
Depth: 28.8 in
Height: 3.4 in
Weight: 32.54 lbs
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Humidity Range Operating: 8 - 90% (non-condensing)
COO: CHINA / CZECHIA / MEXICO / SINGAPORE
