HP e Dl380 Gen10 4214 12lff Perf Ww Svr (P02468B21)
Model: P02468B21
HP e Dl380 Gen10 4214 12lff Perf Ww Svr (P02468B21)
Model: P02468B21
-
HPE DL380 GEN10 4214 12LFF PERF WW SVR
-
Out Of Stock
Product Description
HPE ProLiant DL380 Gen10 server - 2U - Intel Xeon 4214 2.2GHz 12-Core 16.5MB - 16GB RDIMM DDR4 - 1 HPE Smart Array S100i and 1 HPE Smart Array P816i-a/4 GB plus Smart Storage Battery - 331i 4x 1GbE - 3 PCIe 3.0, for detailed descriptions reference the Qui
Product Specs
Manufacturer
HPManufacturer Stock No.
P02468-B21MPN
HPEP02468B21Model#
P02468B21UPC Code
190017340241UNSPSC Code
0Information
Product Description: HPE ProLiant DL380 Gen10 SMB - rack-mountable - AI Ready - Xeon Silver 4214 2.2 GHz - 16 GB - no HDDType: Server - rack-mountable AI Ready
Height (Rack Units): 2U
Localization: Region: Worldwide
Server Scalability: 2-way
Processor: 1 x Intel Xeon Silver 4214 / 2.2 GHz (, up to 3.2 GHz, (12-core)
Processor Socket: FCLGA3647 Socket
Processor Main Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory: 16.5 MB L3 cache
Cache Per Processor: 16.5 MB
RAM: 16 GB (installed) / 1.5 TB (max) - DDR4 SDRAM - Advanced ECC
Storage Controller: RAID (SATA 6Gb/s / SAS 12Gb/s) - PCIe 3.0 x8 (HPE Smart Array P816i-a)
Server Storage Bays: Hot-swap 3.5"
Hard Drive: No HDD
Optical Storage: No optical drive
Video Memory: 16 MB
Networking: 1GbE
Power: AC 120/230 V (50/60 Hz)
Power Redundancy: Yes
Software Included: HPE Server UEFI
Dimensions (WxDxH): 17.5 in x 28.7 in x 3.4 in
Weight: 37.7 lbs
Environmental Standards: ENERGY STAR Qualified
Manufacturer Warranty: Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Type: Server - AI Ready
Product Form Factor: Rack-mountable - 2U
Server Scalability: 2-way
Hot-Swap Bays Qty: 12
Localization: Region: Worldwide
CPU: Intel Xeon Silver 4214
Clock Speed: 2.2 GHz
Max Turbo Speed: 3.2 GHz
Number of Cores: 12-core
CPU Qty: 1
Max CPU Qty: 2
CPU Upgradability: Upgradable
Processor Main Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket: FCLGA3647 Socket
Chipset Type: Intel C621
Installed Size: L3 cache - 16.5 MB
Cache Per Processor: 16.5 MB
Installed Size: 16 GB (installed) / 1.5 TB (max)
Technology: DDR4 SDRAM - Advanced ECC
Effective Memory Speed: 2400 MHz
Rated Memory Speed: 2933 MHz
Form Factor: DIMM 288-pin
Slots: 24 (total) / 23 (empty)
Features: Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory, 6-channel memory architecture
Configuration Features: 1 x 16 GB
RAM Supported: 3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC ¦ 192 GB Non-Volatile - ECC
Type: No HDD
Type: 1 x RAID - PCIe 3.0 x8
Controller Interface Type: SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name: HPE Smart Array P816i-a
Channel Qty: 16
RAID Level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size: 2 GB
Type: No optical drive
Monitor Type: None.
Video Memory: 16 MB
Video Interfaces: VGA
Ethernet Ports: 4 x Gigabit Ethernet
Ethernet Controller: HPE 331i
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol: SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller: Integrated Lights-Out 5
Features: Wake on LAN (WoL), PXE support
Bays: 12 (total) / 12 (free) x hot-swap 3.5" LFF
Slots: 1 (total) / 1 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces: 4 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 1 x VGA (1 rear) ¦ 8 x SATA-600 / SAS 3.0 ¦ 1 x HPE iLO - Type A (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Included Accessories: Cable management arm, 6 performance fans, LFF Easy Install rails
Compliant Standards: AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Device Type: Power supply - hot-plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1 (with optional power supply)
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50/60 Hz)
Power Provided: 800 Watt
OS Certified: SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Software: HPE Server UEFI
ENERGY STAR Certified: Yes
ENERGY STAR Version: 2.1
Service & Support: Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Width: 17.5 in
Depth: 28.7 in
Height: 3.4 in
Weight: 37.7 lbs
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Humidity Range Operating: 8 - 90% (non-condensing)
COO: UNITED STATES
TAA compliance: Yes
