HP Aruba Ap-505h (us) Unified Ap (R3V48A)
HP Aruba Ap-505h (us) Unified Ap (R3V48A)
-
ARUBA AP-505H (US) UNIFIED AP
-
In Stock
Product Description
Aruba 500H Series Unified Hospitality Access Points - 2.4 GHz;5 GHz - Wireless - WLAN Access Points - (1) HPE SmartRate RJ-45 port, auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX. 2.5 Gbps speed complies with NBASE-T and 802.3bz specifications
Product Specs
Manufacturer
HPManufacturer Stock No.
R3V48AMPN
HPER3V48AModel#
R3V48AUPC Code
190017395722UNSPSC Code
0Information
Product Description: HPE Aruba AP-505H (US) Unified Hospitality - wireless access point Bluetooth, Wi-Fi 6Device Type: Wireless access point
Form Factor: In-ceiling
Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Frequency Band: 2.4 GHz, 5 GHz
Performance: Maximum data rate (2.4 GHz): 287 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Aggregate throughput: 1.5 Gbps
Capacity: Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 8
OS Required: ArubaOS, InstantOS
Power Over Ethernet (PoE) Supported: PoE
Pricing Type: BTO
Dimensions (WxDxH): 3.4 in x 1.9 in x 5.9 in
Weight: 12.7 oz
Manufacturer Warranty: Limited lifetime warranty
Device Type: Wireless access point
Width: 3.4 in
Depth: 1.9 in
Height: 5.9 in
Weight: 12.7 oz
Form Factor: In-ceiling
Connectivity Technology: Wireless
Data Transfer Rate: 1.2 Gbps
Line Coding Format: CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum Method: OFDM, DSSS, OFDMA
Frequency Band: 2.4 GHz, 5 GHz
Performance: Maximum data rate (2.4 GHz): 287 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Aggregate throughput: 1.5 Gbps
Capacity: Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 8
Status Indicators: Port status, power, system, status, PoE, radio
Features: Auto-uplink (auto MDI/MDI-X), Deep Packet Inspection (DPI), IPSec Virtual Private Network (VPN), Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller mode, Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, SU-MIMO technology, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, Energy-Efficient Ethernet (EEE), Orthogonal Frequency Division Multiplexing (OFDM), 2x2 MIMO technology, Very High Throughput (VHT) support, security slot (Kensington security lock compatible), Orthogonal Frequency Division Multiple Access (OFDMA), High Efficiency (HE) support, Target Wait Time (TWT), Advanced IoT Coexistence (AIC)
Encryption Algorithm: SSL, WPA, WPA2, WPA3-Enhanced Open, WPA2-MPSK
Compliant Standards: IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac Wave 2, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Antenna: Internal
Antenna Qty: 2
Directivity: Directional
Gain Level: 5.4 dBi
Internet of Things (IoT) Compatible: Yes
Communications Technology: Bluetooth Low Energy (LE), Zigbee
Interfaces: 4 x 1000Base-T - RJ-45 ¦ 1 x HPE Smart Rate - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x console - micro-USB
Compliant Standards: FCC, EN 60601-1-2, EN 60601-1-1, IEC60950/EN60950, Directive 2014/35/EU, Directive 2014/30/EU, ISED, Directive 2014/53/EU, ETS 300 019 Class 2.3, ETS 300 019 Class 1.2, SIG, IEC/EN 62368-1
Pricing Type: BTO
Power Over Ethernet (PoE) Supported: PoE
Power Consumption Operational: 6 Watt
OS Required: ArubaOS, InstantOS
Shipping Width: 4.4 in
Shipping Depth: 2.1 in
Shipping Height: 6.6 in
Shipping Weight: 15.87 oz
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 5 - 93% (non-condensing)
COO: CHINA
TAA compliance: No
