Cisco C9200l 24-port Poe+, Sfp+ Network Essent (C9200L24P4X1E)
Model: C9200L24P4X1E
Cisco C9200l 24-port Poe+, Sfp+ Network Essent (C9200L24P4X1E)
Model: C9200L24P4X1E
-
C9200L 24-PORT POE+, SFP+ NETWORK ESSENT
-
Special order arrives within 3-7 weeks.
Product Description
C9200L 24-PORT POE+, SFP+ NETWORK ESSENTIALS, 1YR OFFERING
Product Specs
Manufacturer
CiscoManufacturer Stock No.
C9200L-24P-4X-1EMPN
CSCC9200L24P4X1EModel#
C9200L24P4X1EUPC Code
889728198424UNSPSC Code
0Information
Product Description: Cisco Catalyst 9200L - Network Essentials - switch - 24 ports - managed - rack-mountableDevice Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE): PoE+
PoE Budget: 370 W
Performance: Stacking bandwidth: 80 Gbps ¦ Switching capacity: 128 Gbps ¦ Switching capacity with stacking: 208 Gbps ¦ Forwarding rate: 95.23 Mpps
Capacity: Virtual networks: 1 ¦ IPv4 routes: 11000 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Multicast scale: 1000 ¦ ACL scale entries: 1500 ¦ FNF entries: 16000 ¦ VLANs supported: 1024 ¦ Switched virtual interfaces (SVIs): 512 ¦ QoS hardware queues per port: 8 ¦ Packet buffer size: 6 MB
MAC Address Table Size: 16000 entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, IPv4, IPv6, YANG
Features: ACL support, QoS, Rapid PVST+, SRR, PXE support, Energy Efficient Ethernet, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, CoPP, Blue Beacon LED, ZTP, secure boot, PIM, FHS, PVLAN support, CIR, Cisco StackWise-80 technology, Cisco Trust Anchor module, Cisco UADP 2.0
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3bz
Power: AC 100-240 V (50 - 60 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 17.5 in x 1.7 in x 11.3 in
Weight: 10.38 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE): PoE+
PoE Budget: 370 W
Performance: Stacking bandwidth: 80 Gbps ¦ Switching capacity: 128 Gbps ¦ Switching capacity with stacking: 208 Gbps ¦ Forwarding rate: 95.23 Mpps
Capacity: Virtual networks: 1 ¦ IPv4 routes: 11000 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Multicast scale: 1000 ¦ ACL scale entries: 1500 ¦ FNF entries: 16000 ¦ VLANs supported: 1024 ¦ Switched virtual interfaces (SVIs): 512 ¦ QoS hardware queues per port: 8 ¦ Packet buffer size: 6 MB
MAC Address Table Size: 16000 entries
Jumbo Frame Support: 9198 bytes
Routing Protocol: OSPF, RIP, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, IPv4, IPv6, YANG
Encryption Algorithm: 128-bit AES
Features: ACL support, QoS, Rapid PVST+, SRR, PXE support, Energy Efficient Ethernet, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, CoPP, Blue Beacon LED, ZTP, secure boot, PIM, FHS, PVLAN support, CIR, Cisco StackWise-80 technology, Cisco Trust Anchor module, Cisco UADP 2.0
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3bz
RAM: 2 GB
Flash Memory: 4 GB
Interfaces: 24 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 4 x 10GBase-X SFP+ uplink ¦ 1 x network stack device ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45
Power Device: Internal power supply - hot-plug
Max Supported Qty: 2
Power Redundancy: Optional
Power Provided: 600 Watt
Voltage Required: AC 100-240 V (50 - 60 Hz)
MTBF: 390,310 hours
Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35
Software Included: Cisco Network Essentials (1 year)
Width: 17.5 in
Depth: 1.7 in
Height: 11.3 in
Weight: 10.38 lbs
Service & Support: Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature: 23 °F
Max Operating Temperature: 113 °F
Humidity Range Operating: 5 - 90% (non-condensing)
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 5 - 90% (non-condensing)
COO: CHINA / MALAYSIA / CHINA / MALAYSIA
TAA compliance: No
