Xerox makes color the easy, affordable choice with the Xerox Phaser 6010N Color Laser Printer. With best-inclass print speed, it's a powerful, office-friendly solution for your team's printing demands. A smaller footprint means you can locate the Xerox Phaser 6010/N where it's most convenient. Easy installation and pre-loaded toner cartridges make this printer virtually plug-and-play. Superior performance gets your jobs out fast, with print speeds as fast as 12 ppm for color and 15 ppm for black-and-white. Unique Xerox EA Eco toner technology gives you crisp text and printed images with superior gloss, detail and clarity.
Features
Product Description: Xerox Phaser 6010N, printer, color, LED
Printer Type: Workgroup printer, LED, color
Dimensions (WxDxH): 15.5 in x 16.9 in x 11.5 in
Weight: 23.6 lbs
Max Media Size (Standard): Legal
Min Media Size (Custom): 3 in x 5 in
Max Media Size (Custom): 8.5 in x 14 in
Print Speed: Up to 12 ppm, B/W, Letter A Size (8.5 in x 11 in) , Up to 15 ppm, color, Letter A Size (8.5 in x 11 in)
Max Resolution ( B&W ): 600 dpi x 600 dpi
Max Resolution ( Color ): 600 dpi x 600 dpi
Interface: USB, Ethernet 10/100Base-TX
Processor: 384 MHz
RAM Installed ( Max ): 128 MB
Media Type: Envelopes, labels, plain paper, coated paper, recycled paper, cover paper
Total Media Capacity: 160 sheets
Media Handling: 150-sheet input tray, 10-sheet bypass tray
Monthly Duty Cycle: 30000 pages
Networking: Print server, Ethernet, Fast Ethernet
Printer Features: 4-bit depth color technology
Power: AC 120 V
System Requirements: Novell NetWare 5.x, Novell NetWare 6.x, Microsoft Windows XP, Microsoft Windows Server 2003, SunSoft Solaris 10, Microsoft Windows 7, Red Hat Enterprise Linux 4, Novell Open Enterprise Server, Red Hat Fedora Core 4, Microsoft Windows Vista, SuSE Linux 11, SuSE Linux 10.x, Apple MacOS X 10.5 or later, Microsoft Windows Server 2008
Environmental Standards: ENERGY STAR Qualified
Manufacturer Warranty: 1 year warranty
Options
Xerox Phaser 6010N Color Laser Printer: Supplies and Accessories Options
Xerox Phaser 6010N Color Laser Printer Specifications
Part # 6010/N
General
Printer Type:
Workgroup printer, LED, color
Width:
15.5 in
Depth:
16.9 in
Height:
11.5 in
Weight:
23.6 lbs
Printer
Print Speed:
Up to 12 ppm, B/W, Letter A Size (8.5 in x 11 in) , Up to 15 ppm, color, Letter A Size (8.5 in x 11 in)
Built-in Devices:
Status LCD
Connectivity Technology:
Wired
Interface:
USB, Ethernet 10/100Base-TX
Max Resolution ( B&W ):
600 dpi x 600 dpi
Max Resolution ( Color ):
600 dpi x 600 dpi
First Print Out Time B/W:
14 sec
First Print Out Time Color:
17 sec
Color Management Features:
PANTONE Digital Color
Printer Features:
4-bit depth color technology
Media Handling:
150-sheet input tray, 10-sheet bypass tray
Processor
Processor:
384 MHz
RAM
RAM Installed ( Max ):
128 MB
Media Handling
Media Type:
Envelopes, labels, plain paper, coated paper, recycled paper, cover paper
Min Media Size (Custom):
3 in x 5 in
Max Media Size (Custom):
8.5 in x 14 in
Media Sizes:
Letter A Size (8.5 in x 11 in), Legal (8.5 in x 14 in)
Media Weight:
60 g/m2, 163 g/m2
Total Media Capacity:
160 sheets
Media Feeder(s):
1 x autoload, 150 sheets, Legal (8.5 in x 14 in) weight: 60 g/m2, 163 g/m2 , 1 x manual load, 10 sheets, Legal (8.5 in x 14 in) weight: 60 g/m2, 163 g/m2
Output Trays Capacity:
100 sheets
Duty Cycle
Monthly Duty Cycle:
30000 pages
Networking
Networking:
Print server
Connectivity Technology:
Wired
Data Link Protocol:
Ethernet, Fast Ethernet
Expansion / Connectivity
Connections:
1 x Hi-Speed USB, 4 pin USB Type B , 1 x network, Ethernet 10Base-T/100Base-TX, RJ-45
Miscellaneous
Consumables Included:
1 x toner cartridge ( black ), up to 500 pages , 1 x toner cartridge ( cyan ), up to 500 pages , 1 x toner cartridge ( magenta ), up to 500 pages , 1 x toner cartridge ( yellow ), up to 500 pages
Compliant Standards:
CE, GOST, GS, NOM, FCC Part 15 B, EMC, R&TTE, UL 60950-1, CSA C22.2 No. 60950-1-07, Section 508
Power
Power Device:
Power supply, internal
Voltage Required:
AC 120 V
Frequency Required:
50/60 Hz
Power Consumption Operational:
180 Watt
Power Consumption Stand by / Sleep:
31 Watt
Software / System Requirements
Software Included:
Xerox CentreWare IS Embedded Web Server, Xerox CentreWare Web
OS Required:
Novell NetWare 5.x, Novell NetWare 6.x, Microsoft Windows XP, Microsoft Windows Server 2003, SunSoft Solaris 10, Microsoft Windows 7, Red Hat Enterprise Linux 4, Novell Open Enterprise Server, Red Hat
Environmental Standards
ENERGY STAR Qualified:
Yes
Manufacturer Warranty
Service & Support:
1 year warranty
Service & Support Details:
Limited warranty, 1 year
Environmental Parameters
Min Operating Temperature:
50 °F
Max Operating Temperature:
89.6 °F
Humidity Range Operating:
10, 85% (non-condensing)
Sound Emission (Idle):
21 dBA
Sound Emission (Operating):
49 dBA
Dimensions & Weight (Shipping)
Width (Shipping):
21.1 in
Depth (Shipping):
17.4 in
Height (Shipping):
15.3 in
Weight (Shipping):
29.3 lbs
Xerox Phaser 6010N Color Laser Printer Features
Outstanding color
Proven Hi-Q LED print engine consumes low energy and space and
produces low noise. It’s the same breakthrough print engine technology
found in some of our higher-end graphic-arts devices. A print resolution of up to 600 x 600 x 4 dpi delivers an amazing 16 shades of color per pixel. That means a wider color range for more impressive business graphics.
Easy in the office and easy on the network
The main paper tray supports a wide range of custom media and sizes,
from labels to card-stock to envelopes. A convenient 10-sheet manual
feed slot lets you feed media and envelopes without opening and loading
the paper tray. Easy installation onto the network and pre-loaded toner cartridges make this printer virtually plug-and-play.
Productive performance
Don’t let the low price fool you. Whether you choose USB or network
connectivity, the Phaser 6010 printer means business for your desktop
or small team, providing real-world print productivity and a host of
built-in features. Superior performance gets your jobs out fast, with print speeds as fast as 12 ppm for color and 15 ppm for black-and-white.
Xerox Phaser 6010N Color Laser Printer Included Items
Xerox Phaser 6010N Color Laser Printer
Starter 500 page Toner Cartridge
Software and Documentation CD (with Quick Installation Guide,
Quick Use Guide, Features Setup Guide, User Manual)
Power Cable
Xerox Phaser 6010N Color Laser Printer Warranty Information
1.800.814.5410
858.764.8900 Mon-Fri 6AM-4PM PT
