The PDP-504CMX does not disappoint as the anxiously awaited next generation plasma display from Pioneer. With redesigned drive circuitry, called Pure Drive, this panel offers more control and flexibility then ever before. The innovative Expansion Solutions card slot customizes the application of the display by changing out the card. Throw in Energy Star efficiency, special integration features, and a robust service network and you have a plasma display panel that redefines how plasma display monitors ought to be.
Viewable Image Size: 50"
Interface: 15-pin Mini D-Sub (Analog) and DVI-D (Digital)
Native Resolution: 1280 x 768
Brightness (Typical): 1,000 cd/m2
Available Color(s): Black
Environments: PC and Mac compatible
Pioneer PDP-504CMX 50" Plasma Display: Supplies and Accessories Options
Pioneer PDP-504CMX 50" Plasma Display Specifications
Part # PDP-504CMX
Manufacturer Part #
Horizontal: 43.25" Vertical: 24.4" Diagonal: 50"
1280 x 768
Number of Colors (Gray Levels)
1024 grey scales
Input Video Signal
Analog: RGB Digital: DVI
15-pin Mini D-sub (x 1) DVI-D (x 1)
AC 120 V, 50/60 Hz
32º - 104º F
20% - 80%
FCC Class B
Dimensions (W x H x D)
47.9" x 28.125" x 3.8"
All Windows OS
All Mac OS
1 year limited warranty on parts, labor and backlight.
Includes in the Box
Pioneer PDP-504CMX 50" Plasma Display Power Cord Remote Control Unit Remote Control Unit Holder AA (R6) batteries x2 Cleaning cloth (for screen) Speed clamps x2 Bead bands x2 Display stands x2 Washers x2 Hex hole bolts (M8x40) x2 Operating Instructions Warranty Info
Pioneer PDP-504CMX 50" Plasma Display Features
Compatibility with a Wide Range of PC Signals With a native resolution of 1024 x 768, this high precison panel can accuratelty display personal computer signals raging from 640 x 400 and 640 x 480 (VGA) to 1024 x 768 (XGA). It can also support compression (UXGA) signals. In addition, Pioneer's proprietary scailing technology enables a circle to be displayed as a circle onto 1024 x 768 at 16:9 with 1280 x 768 signal input.
Intelligent Auto Setup The Intelligent Auto Setup feature improves both performance and convenience, allowing image adjustment via the remote control. The display incorporates a new function, Auto Adjust, which detects the PC signals and automatically adjusts the position of the image, making it unnecessary to have to push the Auto Setup button.
Three Dual Picture Modes The PDP-434CMX offers a choice of three Dual Picture modes for simultaneous display of images from two connected sources. Split screen shows two images side by side, Picture-in-Picture superimposes a small picture over the full-screen picture in any of the four corners, and Picture-Out-Picture displays the second image on the right side of the screen.
Enhanced Point Zoom The Enhanced Point Zoom function lets you instantly expand any portion of a PC image in three steps (1,5x, 2x, 3x), great for emphasizing key points in the presentations. The Zoom Area sub-display area makes it easy to confirm the expanded portion.
2 x 2 Image Expansion This model allows a 2 x 2 data wall using four units without the need for an expansion device. Two display modes are available, one that enlarge all picture elements so the entire picture is visible, and one that enlarges the whole image so lines between units are not visible.
Color Detail Adjustment Color adjustment ca be performed for any specific color without affecting the other colors. For example, you can change the purplish red of a sports car to crimson without changing other colors in the image.
Large GUI Display Having a GUI display is a definite advantage, making operation considerably easier, but if it is too small to see when the unit is mounted, it usefulness is limited. The PDP-434CMX provides an extra-large display, which is visible even when the unit is mounted in a high location.
Function Lock A number of functions can be locked, making the display system more secure. Lock modes are on/off, main unit buttons, remote control, main input and volume default setings when the unit is turned on.
Pioneer PDP-504CMX 50" Plasma Display Included Items
Pioneer PDP-504CMX 50" Plasma Display
Remote Control Unit
Remote Control Unit Holder
AA (R6) batteries x2
Cleaning cloth (for screen)
Speed clamps x2
Bead bands x2
Display stands x2
Hex hole bolts (M8x40) x2
Pioneer PDP-504CMX 50" Plasma Display Warranty Information
Warranty Length: One year limited warranty.
Coverage: Covers Parts and Labor.
Details: Pioneer Electronics (USA) Inc. (PUSA) warrants that products distributed by PUSA in the U.S.A. that fail to function properly under normal use due to a manufacturing defect when installed and operated according to the owner’s manual enclosed with the unit will be repaired or replaced with a unit of comparable value, at the option of PUSA, without charge to you for parts or actual repair work. Parts supplied under this warranty may be new or rebuilt at the option of PUSA.
Provider: Pioneer Electronics, Inc.
Contact: Pioneer Technical Support at 1-800-421-1625
