Nortel BayStack 5510-24T 24 Port Ethernet Routing Switch

1010652745   Nortel
Free Shipping on Orders over $99!
SKU # AL1001E04-E5GS
Please Call! 1-800-814-5410



Imageicon


The Nortel Ethernet Routing Switch 5510 models are 1 rack unit high next-generation stackable 10/100/1000 Mbps Ethernet Layer 3 routing switches designed to provide high-density Gigabit desktop connectivity to mid-size and large enterprise customers' wiring closets. Ethernet Routing Switch 5510-24T offers 24 10/100/1000BASE-T RJ-45 ports for desktop switching and two built-in SFP GBIC ports for uplink. Port 23 and Port 24 offer configuration flexibility as either a 10/100/1000 or a built-in SFP GBIC.
  • Product Description: Nortel Ethernet Routing Switch 5510-24T, switch, 24 ports
  • Device Type: Switch, stackable
  • Form Factor: External, 1U
  • Dimensions (WxDxH): 17.2 in x 15.2 in x 1.8 in
  • Weight: 12.8 lbs
  • Localization: North America
  • Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
  • Data Transfer Rate: 1 Gbps
  • Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
  • Empty Slots: 2 x shared SFP (mini-GBIC)
  • Remote Management Protocol: RMON 2, SNMP, RMON, Telnet, SNMP 3, HTTP
  • Communication Mode: Half-duplex, full-duplex
  • Features: Flow control, full duplex capability, layer 3 switching, IP-routing, auto-correction of twisted-pair polarity reverse, auto-negotiation, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, port mirroring, DiffServ support, manageable, stackable, MAC address filtering
  • Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s

General
Device Type: Switch, stackable
Enclosure Type: External, 1U
Width: 17.2 in
Depth: 15.2 in
Height: 1.8 in
Weight: 12.8 lbs
Localization: North America
Networking
Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Max Units In A Stack: 8
Data Transfer Rate: 1 Gbps
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol: OSPF, RIP-1, RIP-2, static IP routing
Remote Management Protocol: RMON 2, SNMP, RMON, Telnet, SNMP 3, HTTP
Connectivity Technology: Wired
Communication Mode: Half-duplex, full-duplex
Switching Protocol: Ethernet
MAC Address Table Size: 16K entries
Status Indicators: Link activity, port transmission speed, port duplex mode, power, status
Features: Flow control, full duplex capability, layer 3 switching, IP-routing, auto-correction of twisted-pair polarity reverse, auto-negotiation, BOOTP support, ARP support, trunking, VLAN support, auto-uplink
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Expansion / Connectivity
Expansion Slots Total (Free): 2 ( 2 ) x SFP (mini-GBIC)
Interfaces: 24 x network, Ethernet 10Base-T/100Base-TX/1000Base-T, RJ-45 , 1 x management, 9 pin D-Sub (DB-9) , 2 x network stack device
Miscellaneous
Cables Included: 1 x stacking cable, 1.5 ft
Authentication Method: Secure Shell (SSH), RADIUS, Secure Shell v.2 (SSH2)
Compliant Standards: UL, BSMI CNS 13438 Class A, cUL, EN 60950, EN 61000-3-2, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, CSA 22.2 No. 60950, CB, AS/NZ 3548 Class A, ICES-003 Class A, RoHS
Pricing Type: Government / Trade Agreements Act (TAA) Compliance
Power
Power Device: Power supply, internal
Voltage Required: AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 135 Watt
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 113 °F
Humidity Range Operating: 0, 85%
