The MegaRAID SATA 150-4, with four Serial ATA 150 I/O ports, offers powerful SATA RAID functionality for server, workstation and network storage environments. Built around intelligent and proven MegaRAID technology, the MegaRAID SATA 150-4 is a half-size, four-port SATA RAID controller with support for RAID levels 0, 1, 5 and more. The MegaRAID SATA 150-4 also boasts a vast array of on-line and remote management features including on-line capacity expansion and RAID level migration to make GUI-based storage management quick and easy to use.
Controller Interface: Serial ATA-150
Number of Ports: 4 Serial ATA
RAID Support: RAID 0, 1, 5, 10 and 50
Data Transfer Rate: Up to 150 MB/Second
Bus Type: 64-bit, 66MHz PCI
Environments: Microsoft Windows 2000, XP, or 2003; Novell Netware; SuSE Linux, SuSE Linux Enterprise Server; SCo OpenLinux Server, SCO UnixWare; RedHat Linux
LSI Logic MegaRAID SATA 150-4 Serial ATA RAID Controller: Supplies and Accessories Options
LSI Logic MegaRAID SATA 150-4 Serial ATA RAID Controller Specifications
Part # 1504064
MegaRAID SATA 150-4
Manufacturer Part #
Controller Interface Type
Data Transfer Rate
Up to 150 MB/Second
0, 1, 5, 10 and 50
64-bit, 66 MHz PCI
4 x 7 Pin Serial ATA
Expansion / Connectivity
4 x Serial ATA
4 x Serial ATA (1 Meter Length)
32° - 113° F
Dimensions (W x H)
6.875" x 4.2"
Microsoft Windows 2000, XP, or 2003; Novell Netware; SuSE Linux, SuSE Linux Enterprise Server; SCo OpenLinux Server, SCO UnixWare; RedHat Linux
Three year limited warranty with free advanced technical support and advanced replacement option.
Includes in the Box
LSI Logic MegaRAID SATA 150-4 Controller Card Four 1 Meter Serial ATA Cables Driver CD Installation Guide
LSI Logic MegaRAID SATA 150-4 Serial ATA RAID Controller Features
Workstations and entry to mid-level servers requiring a cost effective, scalable SATA RAID solution.
Database, file, web and email servers; multimedia and video servers.
Designed as a “ready-to-go” solution
Four 1-meter SATA cables included
Half-size PCI form factor
Intel GC80302 integrated I/O processor
RAID array availability in minutes instead of hours
