On paper, the Kodak i780 Scanner outruns the competition with speeds up to 130 ppm. But unlike competing products, it delivers that maximum scanning while meeting real needs under real world conditions. You get true 130 ppm performance, even when scanning at up to 300 dpi resolution; in color, grayscale or black-and-white; in dual stream mode (outputting up to four images per scan); and with all advanced features enabled. Real-world performance makes the Kodak i780 Scanner the one to choose for mission-critical, high-volume forms processing across a broad range of applications. The Kodak i780 model easily scans mixed batches of business documents, photos, tear sheets and graphics. A flexible input design enables it to handle a wide range of document sizes and shapes. And an included short-document exit tray allows for efficient stacking of smaller documents. Kodak's SurePath technology delivers the paper-feeding reliability you need for uninterrupted workflow—while ultrasonic multi-feed detection helps prevent misfeeds by recognizing labels, stick-on notes, and stuck-together documents.
Scanner Type: Flatbed
Document Handling: 500-sheet elevator-design automatic document feeder with four settings: continuous feed, 100-sheet, 250-sheet and full 500-sheet batches
Kodak i780 Sheetfed Scanner ADF Specifications
Part # 1200013
Manufacturer Part #
Dual Tricolor Plus CCD
300 dpi x 300 dpi
Max. Scan Area
12" x 34"
130 pages per minute, up to 520 images per minute
(Images per minute speeds based on dual stream output of four compressed images for each document scanned-bitonal and color or bitonal and grayscale)
IEEE-1394 (Firewire) Interface, 6-pin connector
IEEE-1394 card and cable included
2.5" x 2.5" - 12" x 34"
With Standard feeder: 45 g/m² (12 lb.) bond to 200 g/m² (110 lb.) index
With Ultra-Lightweight feeder accessory: 25 g/m² (7 lb.) rice paper to 75 g/m² (20 lb.) bond
CCITT Group IV; JPEG or uncompressed output
< 61 dB
< 42 dB
AS/NZS CISPR 22 Class B (C-Tick Mark), CAN/CSA-C22.2 No. 60950-1-03, Canada ICES-003 Issue 3 (Class A), GB4943, GB9254 (Class A), GB 17625.1 Harmonics (CCC “S&E” Mark), EN 55022: 2006 ITE Emissions (Class B), EN 61000-3-3 Flicker, EN 55024:1998 ITE Immunity, (CE Mark), EN 60950-1 (TUV GS Mark), IEC 60950-1, CISPR 22 (Class B), VCCI (Class A), CNS 13438:2006 (Class A), (BSMI Mark), UL 60950-1, CFR 47 Part 15 Subpart B (FCC Class A), Argentina S-Mark
100-240 V, 50/60 Hz
200 watts maximum
15% to 76%
(W x H x D)
23.9" x 15.7" x 30.3
Windows 2000 SP4, Windows XP SP2, Windows Vista (32-bit)
Kodak i780 Sheetfed Scanner ADF Features
No presorting needed—with the automatic orientation feature, document content is analyzed on the fly and your images are automatically displayed in the correct reading orientation.
Exclusive Perfect Page imaging delivers exceptional image quality, with readability equal to or better than the original document.
Auto color detection for threshold-based automatic color scanning.
Electronic color dropout allows the scanner to eliminate the form color, capturing only the information you need.
Auto cropping, so you capture only the actual document—and deskew, to automatically straighten every image.
Five output options meet virtually any imaging requirement—black-and-white, color or grayscale, plus two dual stream options: color and black-and-white, or grayscale and black-and- white.
Kodak i780 Sheetfed Scanner ADF Warranty Information
Warranty Length: 90 Days
Covers: Parts and Labor
Details: Kodak warrants your KODAK Scanner to be free from malfunctions and defects in both materials and workmanship for 90 days from the date of purchase. If this equipment does not function properly during the warranty period due to defects in material or workmanship, Kodak will, at its option, either repair or replace the equipment without charge, subject to the conditions and limitations stated herein. Such repair service will include all labor as well as any necessary adjustments and/or replacement parts.
Contact: By Phone: (800) 225-5352 (8:00AM - 6:00 PM EST)
