For high-end data center applications, virtualization platforms, or as a video server, the Intel Server System SR2600UR features up to five expansion slots, six 3.5" drive bays, and redundant cooling, all in a 2U rack mount chassis.
Features
Product Description: Intel Server System SR2612URR, no CPU
Type: Server
Form Factor: Rack-mountable, 2U
Dimensions (WxDxH): 17.2 in x 30.7 in x 3.4 in
Localization: North America
Server Scalability: 2-way
Processor: No CPU
Processor Socket: LGA1366 Socket
RAM: 0 MB (installed) / 96 GB (max), DDR3 SDRAM
Storage Controller: RAID ( Serial ATA-300 )
Server Storage Bays: Hot-swap 3.5"
Hard Drive: None.
Monitor: None.
Graphics Controller: ServerEngines Pilot II
Video Memory: 8 MB DDR2 SDRAM
Networking: Network adapter, Ethernet, Fast Ethernet, Gigabit Ethernet, Ethernet Ports : 2 x Gigabit Ethernet
Power Redundancy: Yes
Manufacturer Warranty: 3 years warranty
Intel Server System SR2612URR Rack Server Specifications
Part # SR2612URRNA
General
Type:
Server
Product Form Factor:
Rack-mountable, 2U
Server Scalability:
2-way
Front Accessible Bays Qty:
1
Hot-Swap Bays Qty:
12
Width:
17.2 in
Depth:
30.7 in
Height:
3.4 in
Localization:
North America
Processor
Type:
No CPU
Max Supported Qty:
2
Upgradability:
Upgradable
Mainboard
Processor Socket:
LGA1366 Socket
Chipset Type:
Intel 5520
RAM
Installed Size:
0 MB / 96 GB (max)
Technology:
DDR3 SDRAM
Form Factor:
DIMM 240-pin
Features:
Unbuffered, registered
Storage Controller
Type:
1 x RAID, integrated
Controller Interface Type:
Serial ATA-300
Channel Qty:
6
RAID Level:
RAID 0, RAID 1, RAID 10
Storage
Hard Drive:
None.
Monitor
Monitor Type:
None.
Graphics Controller
Type:
Integrated
Graphics Processor / Vendor:
ServerEngines Pilot II
Video Memory:
8 MB DDR2 SDRAM
Networking
Networking:
Network adapter
Ethernet Ports:
2 x Gigabit Ethernet
Ethernet Controller(s):
2 x Intel 82575
Data Link Protocol:
Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity
Expansion Bays Total (Free):
12 ( 12 ) x hot-swap, 3.5" , 1 ( 1 ) x front accessible, 5.25" Slim Line
2 x network, Ethernet 10Base-T/100Base-TX/1000Base-T, RJ-45 , Display / video, VGA, 15 pin HD D-Sub (HD-15) , Serial, RJ-45 , 4 x Hi-Speed USB, 4 pin USB Type A
Miscellaneous
Included Accessories:
Rack mounting kit
Power
Device Type:
Power supply, hot-plug
Power Redundancy:
Yes
Power Redundancy Scheme:
1+1
Installed Qty:
2
Max Supported Qty:
2
Power Provided:
760 Watt
Manufacturer Warranty
Service & Support:
3 years warranty
Service & Support Details:
Limited warranty, 3 years
