Adaptable, reliable mainstay for your business. The HP ProLiant ML350 G6 Server is the best price performance DP Tower server that delivers excellence with performance, expandability and availability. It's a new generation server with more memory capacity and more HDD expandability. It combines the latest Intel Xeon processors with QPI technology, best-in-class availability features, and unsurpassed flexibility in a system ideal for growing businesses and especially well suited to meet the needs of remote branch offices.
Features
Product Description: HP ProLiant ML350 G6, Xeon E5506 2.13 GHz
Storage Controller: RAID ( Serial ATA-150 / SAS ), PCI Express x4 ( Smart Array P410i ) ; Serial ATA
Server Storage Bays: Hot-swap 3.5"
Hard Drive: None.
Optical Storage: DVD-ROM
Monitor: None.
Graphics Controller:, 64 MB
Networking: Network adapter, PCI Express x4, Ethernet, Fast Ethernet, Gigabit Ethernet, Ethernet Ports : 2 x Gigabit Ethernet
Power: AC 120/230 V ( 50/60 Hz )
Power Redundancy: Optional
Manufacturer Selling Program: HP Smart Buy
Manufacturer Warranty: 3 years warranty ( on-site )
HP ProLiant ML350 G6 516283-005 Tower Server Specifications
Part # 516283-005
General
Type:
Server
Recommended Use:
Small business, corporate business
Product Form Factor:
Tower, 5U
Server Scalability:
2-way
Front Accessible Bays Qty:
5
Hot-Swap Bays Qty:
6
Width:
8.6 in
Depth:
23.5 in
Height:
18.5 in
Weight:
54 lbs
Processor
Type:
Intel Xeon E5506 / 2.13 GHz
Multi-Core Technology:
Quad-Core
64-bit Computing:
Yes
Installed Qty:
1
Max Supported Qty:
2
Upgradability:
Upgradable
Cache Memory
Type:
L3 cache
Installed Size:
4 MB
Cache Per Processor:
4 MB
Mainboard
Chipset Type:
Intel 5520
RAM
Installed Size:
2 GB / 144 GB (max)
Technology:
DDR3 SDRAM
Memory Speed:
1333 MHz
Memory Specification Compliance:
PC3-10600
Form Factor:
DIMM 240-pin
Features:
Registered
Configuration Features:
1 x 2 GB
Storage Controller
Type:
1 x RAID, plug-in card, PCI Express x4
Controller Interface Type:
Serial ATA-150 / SAS
Storage Controller Name:
Smart Array P410i
RAID Level:
RAID 0, RAID 1, RAID 10
Storage Controller (2nd)
Type:
1 x Serial ATA, integrated
Storage
Hard Drive:
None.
Optical Storage
Type:
DVD-ROM, Serial ATA
Monitor
Monitor Type:
None.
Graphics Controller
Type:
Integrated
Installed Size:
64 MB
Networking
Networking:
Network adapter, PCI Express x4, integrated
Ethernet Ports:
2 x Gigabit Ethernet
Ethernet Controller(s):
HP NC326i
Data Link Protocol:
Ethernet, Fast Ethernet, Gigabit Ethernet
Features:
Wake on LAN (WoL)
Compliant Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Expansion Bays Total (Free):
5 ( 4 ) x front accessible, 5.25" x 1/2H , 6 ( 6 ) x hot-swap, 3.5" x 1/3H
Expansion Slots Total (Free):
4 ( 4 ) x PCI Express x8 ( x4 mode ) , 18 ( 16 ) x memory, FB-DIMM 240-pin , 2 ( 1 ) x processor , 1 ( 1 ) x PCI Express x16 ( x8 mode ) , 1 ( 1 ) x PCI Express x8
Interfaces:
1 x display / video, VGA, 15 pin HD D-Sub (HD-15) , 1 x keyboard, generic, 6 pin mini-DIN (PS/2 style) , 1 x mouse, generic, 6 pin mini-DIN (PS/2 style) , 1 x serial, RS-232, 9 pin D-Sub (DB-9
Miscellaneous
Features:
System password, power-on password, disk configuration lock, diskette I/O control, parallel port I/O control, serial port I/O control
Compliant Standards:
ACPI 2.0
Manufacturer Selling Program:
HP Smart Buy
Power
Device Type:
Power supply, hot-plug
Power Redundancy:
Optional
Power Redundancy Scheme:
1+1 (with optional power supply)
Installed Qty:
1
Max Supported Qty:
2
Voltage Required:
AC 120/230 V ( 50/60 Hz )
Power Provided:
750 Watt
Operating System / Software
OS Certified:
Microsoft Windows 2000 Server, Microsoft Windows 2000 Advanced Server, Red Hat Linux, SuSe Linux, SCO OpenServer 5.0.7, Microsoft Windows Server 2003 Enterprise Edition, Microsoft Windows Server 2003
Software:
Drivers & Utilities
Manufacturer Warranty
Service & Support:
3 years warranty
Service & Support Details:
Limited warranty, parts and labor, 3 years, on-site
Environmental Parameters
Min Operating Temperature:
50 °F
Max Operating Temperature:
95 °F
HP ProLiant ML350 G6 516283-005 Tower Server Features
Growing Business
Offers excellent price-performance and value. Modular chassis provides the flexibility to deploy in tower or rack environment. Offers deployment capabilities while ensuring physical security. Provides great expandability for room to grow.
Remote and Branch office Deployment
Whisper quiet fans are ideal for the small office environment. HP Onboard Administrator (powered by embedded iLO 2 controller) provides secure and dedicated remote management and control for communicating with headquarter. Flexible memory configuration provides low cost memory expansion. Integrated dual Gigabit Ethernet provides increased network throughput and redundancy with efficiency.
Mid Market and Entry Enterprise
Ultimate performance with processors up to 2.93GHz, 8M cache and 6.4GT/s QPI technology with Turbo mode. Advanced RAID protection takes high availability for HDD efficiency. Redundant power and fan reduce downtime by maintaining system performance. Virtualization ready- tested and certified for virtualized environments.
HP ProLiant ML350 G6 516283-005 Tower Server Warranty Information
Limited warranty, parts and labor, 3 years, on-site
