The 42 inch HP Designjet 800PS Plotter with an included Adobe PostScript 3 RIP, provides detailed illustrations, accurate proofs and power presentations for advertising agencies, design studios, and graphics workgroups. HP Designjet 800 Series plotters are network-ready, and contain a "virtual computer" inside, which boosts productivity by doing all of the file processing work, thus, freeing up the computer quickly. The HP Designjet 800PS plotter is perfect for architectural firms, engineering departments and other technical groups relining on fast, accurate illustrations, precise line drawings, and high-resolution renderings. Producing color images at 85 square feet/hr (D size fast mode) and line drawings in just 60 seconds the 800PS uses its 160MB of RAM and 6GB of hard disk space to its advantage when it comes to getting media out the door. The 800PS has precise ink placement technology that ensures crisp, sharp lines and text. When this printer is combined with HP's color layering technology, users can create smooth color transitions and photo quality results.
Features
Print Size: 42" x 150' Max
Print Speed: 36 Sq. Ft. Per Hour
Resolution: 2400 x 1200 dpi
Memory: 160 MB (Max)
Hard Drive: 6 GB
Connectivity: USB, Parallel and 10/100Base-TX Ethernet
Adobe PostScript 3 Enabled
Environments: PC, AutoCAD, and UNIX
Warranty: 1 Year On Site covering parts and labor
Printer Stand and Media Bin Included
Options
HP DesignJet 800PS (42"): Supplies and Accessories Options
HP DesignJet 800PS (42") Specifications
Part # C7780C
Key Specifications
DesignJet 800PS (42")
Manufacturer Part #
C7780C
Print Technology
HP Thermal Inkjet
Color Control
PhotoREt III HP Color Layering Technology Uses more color levels to deliver higher quality printing without the disadvantages of higher DPI, such as slow printing speed and larger file sizes.
Print Speed
Fast Mode: Line drawings: 90 seconds, color images: 85 sq. ft./hr Normal Mode: 36 sq. ft./hr Best Quality: 21 sq. ft./hr
Resolution
2400 X 1200 DPI with HP Color Layering Technology
Connectivity
Ports
Centronics parallel IEEE 1284-compliant (ECP) USB 1.1 (Windows 98, 2000, and Mac OS 8.5, 8.6, 9.0 only)
Optional Network Ports
HP Jetdirect 600n / 610n (EIO) internal print servers (Part #: J3111A) HP Jetdirect 500x, 300x, and 170x external print servers
Networking
Network Management
HP Jetdirect EIO internal print server for Fast Ethernet 10/100Base-TX
Languages and Fonts
Adobe® PostScript® 3, HP-GL/2, HP RTL, CALS G4 (TIFF and JPEG files from UNIX®, Linux and Windows NT via ZEHRaster Plus)
Typefaces
136 PostScript® built-in Roman fonts, Asian PostScript fonts in-the-box, Morisawa fonts for Japan, support for Sandoll, Hancom and Yoon PS fonts and Arphic for Taiwan
Memory
160 MB RAM (Max)
Hard Drives
6 GB
Paper Handling
Input
Single Sheet Feed Roll Feed
Media Cuter
Automatic Cutter
Types/Sizes
Media Types: Bright White Inkjet Paper (bond), Translucent Bond, Natural Tracing Paper, Vellum, Clear Film, Matte Film, Coated Paper, Heavyweight Coated Paper, High-Gloss Photo Paper, Semi-Gloss Photo Paper, Paper-Based Semi-Gloss, Satin Poster Paper, Studio Canvas, Banners with Tyvek, Colorfast Adhesive Vinyl Media Sizes: 8.3" to 24" wide sheets; 24", 36", and 42" rolls, maximum print length: 150'
Misc. Features
Power Requirements
100 to 240 V AC ±10% auto-ranging; 50 to 60 Hz, 3 amps maximum
Power Consumption
150 W
Noise Levels
Printing: 52 dBA Operating: 65 dBA
Temperature
Operating: 59°F to 95°F (15°C to 35°C) Storage: –40°F to 158°F (-40°C to 70°C)
Humidity
Operating: 20% to 80% RH
Environmental Features
US EPA Energy Star® compliant
Regulatory Compliance
Information and Safety: Compliant with the requirements for the ITE products—EU: Low Voltage Directive; USA and Canada: CSA Certified for US and Canada; Mexico: NOM-1-NYCE; Argentina: IRAM; China: CCIB and CCEE; Singapore: PSB; Russia: GOST; Poland: PCBC.
Electromagnetic Compatibility: Compliant with the requirements for Class B ITE products (Class A when connected to LAN cables)—EU EMC Directive, USA FCC rules, Canada DOC, Australia ACA, New Zealand MoC, China CCIB, Japan VCCI. Class A for Korea MIC, Taiwan BSMI.
Supplies
Plotter Ink
These toners are designed specifically for the HP DesignJet 800 Series: Ink Types: Pigment-based black, Dye-based color Black Ink Cartridge (Part #: C4844A) Yields 1,430 pages @ 5% coverage Cyan Ink Cartridge (Part #: C4911A) Yields 1,430 pages @ 5% coverage Magenta Ink Cartridge (Part #: C4912A) Yields 1,430 pages @ 5% coverage Yellow Ink Cartridge (Part #: C4913A) Yields 1,430 pages @ 5% coverage
Other Supplies
Black Print Head (Part #: C4810A) Cyan Print Head (Part #: C4811A) Magenta Print Head (Part #: C4812A) Yellow Print Head (Part #: C4813A) 42" spindle (Part #: C2390A) Fiery X4-W external RIP (Part #: C7789A)
Software Features
Drivers Included: Microsoft® Windows (95, NT) without USB; Windows (98, 2000) with USB; Macintosh OS 8.1+; AutoCAD 2000 and Releases 13, 14 for Windows
Dimensions (H X W X D)
Unit
43" X 67" X 27"
As Shipped
78" X 25" X 38"
Weight
Unit
99 lb
As Shipped
257 lb
Warranty
1 year on-site warranty includes parts and labor. This warranty does not include replacement of consumables such as toner. Super Warehouse offers a wide array of extended warranties which can add 2 to 4 years of coverage.
HP DesignJet 800PS (42") Features
High Speed
• Color images at 85 ft2/hr (D-size fast mode)
• Line drawings in just 60 seconds (D-size super fast mode)
Uncompromising Image Quality
• Up to 2400 dpi resolution (on glossy media)
• Rich, brilliant colors from print to print, regardless of ink levels or print head usage
• Precise ink placement ensures crisp, sharp lines and text
• HP color layering technology combines ink drops on a single dot to create smooth color transitions and photo-quality results -- even up close
Smart Printing
• "Virtual computer" inside processes files, quickly freeing up the computer
• Supports queuing, nesting and processes the next job while printing
• High capacity HP No. 82 ink cartridges and long life HP No. 11 print heads mean fewer supplies changes, unattended printing and low cost of ownership
• Network ready -comes ready to print right out of the box
• Ink cartridges and print heads are replaceable - replace what you need, when you need
• HP Zoomsmart scaling technology allows easy large-format printing from any Windows application and easily enlarges any image
• Optional EFI Fiery X4-W external RIP provides EFI tools and workflow for design professionals
Simple To Use
• Drivers are easy to install and the control panel is simple to navigate
• Smooth media loading and automatic alignment
• Ink set changes take less than one minute
• Finished prints are automatically cut and stacked (optional on 24-inch models)
Designjet 800PS
• 160 MB RAM and 6 GB hard disk (standard and maximum)
• Color management obtained through automatic Pantone calibration, offset printing press emulations EuroScale, SWOP, DIC and TOYO), ICC profiles for Windows and Macintosh (800PS only). Pantone Certified
• Pantone certified
HP DesignJet 800PS (42") Included Items
HP Designjet 800PS Plotter
Built-in HP Jetdirect 10/100 BASE-TX network card
Spindle
Power cord
Ink cartridges
Printheads
Roll of media
HP-GL/2
PostScript and AutoCAD Drivers
ZEHRaster Plus for UNIX
HP install network wizard
User documentation
Printer Stand
Media Bin
HP DesignJet 800PS (42") Warranty Information
Warranty Length: Manufacturer One Year Next Business Day On Site Warranty
Covers: Parts and Labor
Contact: By Phone: 800-752-0900 Technical Support 800-474-6836
