Gigabyte GA-G31M-ES2L Motherboard

1012170758   Gigabyte
Free Shipping on Orders over $99!
SKU # GA-G31M-ES2L
Please Call! 1-800-814-5410



Imageicon


The GA-G31M-ES2L supports Intel's latest high performance CPU that delivers the most energy-efficient performance available today. Based on Intel's Micro Architecture, the Intel multi-core processors with 4 cores and two shared L2 caches provide the best capability-per-watt solutions and are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments. This cutting-edge processor offers significant performance boosts and provides a more energy efficient platform. Featuring an advanced proprietary software design, GIGABYTE Easy Energy Saver is able to dynamically adjust CPU power depending on workload, delivering just the right amount of power needed for the task. Coupled with Intel's highly efficient 45nm CPU's, Easy Energy Saver is able to provide exceptional levels of power savings and enhanced power efficiency without sacrificing computing performance.
  • Product Description: Gigabyte GA-G31M-ES2L, motherboard, micro ATX, iG31
  • Product Type: Motherboard
  • Form Factor: Micro ATX
  • Dimensions (WxDxH): 9.6 in x 7.6 in
  • Chipset Type: Intel G31 Express / Intel ICH7
  • Multi-Core Support: Dual-Core / Quad-core
  • Max Bus Speed: 1600 MHz
  • Processor: 0 ( 1 ), LGA775 Socket
  • Compatible Processors: Core 2 Duo, Core 2 Quad, Pentium Dual Core, Celeron 400 sequence, Celeron Dual Core
  • 64-bit Processors Compatibility: Yes
  • RAM: 0 MB (installed) / 4 GB (max)
  • Supported RAM Technology: DDR2 SDRAM
  • Storage Controller: ATA-100, Serial ATA-300
  • USB Ports Configuration: 8 x USB
  • Storage Ports Configuration: 1 x ATA, 4 x SATA
  • Graphics Controller: Intel GMA 3100, Dynamic Video Memory Technology 4.0
  • Audio Output: Sound card, 7.1 channel surround
  • Networking: Network adapter, Realtek RTL8111C, Ethernet, Fast Ethernet, Gigabit Ethernet

General
Product Type: Motherboard
Form Factor: Micro ATX
Width: 9.6 in
Depth: 7.6 in
Compatible Processors: Core 2 Duo, Core 2 Quad, Pentium Dual Core, Celeron 400 sequence, Celeron Dual Core
64-bit Processors Compatibility: Yes
Processor Socket: LGA775 Socket
Multi-Core Support: Dual-Core / Quad-core
Chipset Type: Intel G31 Express / Intel ICH7
Max Bus Speed: 1600 MHz
BIOS Type: Award
Storage Controller: ATA-100, Serial ATA-300
Power Connectors: 4-pin ATX12V connector, 24-pin main power connector
Processor
Installed Qty (Max Supported): 0 ( 1 )
Memory
Supported RAM Technology: DDR2 SDRAM
RAM Installed ( Max ): 0 MB / 4 GB (max)
Supported RAM Speed: PC2-6400, PC2-5300, PC2-8500
RAM Features: Two DDR channels
Video
Graphics Controller: Intel GMA 3100
Video Memory: Dynamic Video Memory Technology 4.0
Audio
Audio Output: Sound card
Audio Codec: Realtek ALC883
Sound Output Mode: 7.1 channel surround
Compliant Standards: High Definition Audio
Telecom / Networking
Networking: Network adapter, Realtek RTL8111C, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
BIOS Features: DMI 2.0 support, ACPI 1.0b support, SMBIOS 2.4 support
Hardware Monitoring: CPU core temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection
Hardware Features: Chassis intrusion detection, Q-Flash, C.O.M. (Corporate Online Management), Virtual Dual BIOS, GIGABYTE Easy Energy Saver
Expansion / Connectivity
Expansion Slot(s): 1 processor, LGA775 Socket , 2 memory ( 1.8 V ), DIMM 240-pin , 1 PCI Express x16 , 1 PCI Express x1 , 2 PCI
Storage Interfaces: Intel ICH7 : Serial ATA-300, connector(s): 4 x 7pin Serial ATA, 4 device(s) , Intel ICH7 : ATA-100, connector(s): 1 x 40pin IDC, 2 device(s)
Interfaces: 1 x audio, line-in, 4 pin MPC , 1 x storage, floppy interface, 34 pin IDC , 1 x keyboard, generic, 6 pin mini-DIN (PS/2 style) , 1 x mouse, generic, 6 pin mini-DIN (PS/2 style) , 1 x parallel
Additional Connectors (Optional): 4 x Hi-Speed USB
Miscellaneous
Cables Included: 1 x IDE cable , 1 x floppy cable , 2 x Serial ATA cable
Software Included: Drivers & utilities, Norton Internet Security, @BIOS, Xpress Recovery 2
Compliant Standards: Plug and Play, ACPI 1.0b, RoHS
