Gigabyte GA-G31M-ES2L Motherboard

Gigabyte ga g31m es2l   Gigabyte
Save money with a Superwarehouse Gift Card!
SKU # GA-G31M-ES2L
Availability: No Stock



    Imageicon

    The GA-G31M-ES2L supports Intel's latest high performance CPU that delivers the most energy-efficient performance available today. Based on Intel's Micro Architecture, the Intel multi-core processors with 4 cores and two shared L2 caches provide the best capability-per-watt solutions and are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments. This cutting-edge processor offers significant performance boosts and provides a more energy efficient platform. Featuring an advanced proprietary software design, GIGABYTE Easy Energy Saver is able to dynamically adjust CPU power depending on workload, delivering just the right amount of power needed for the task. Coupled with Intel's highly efficient 45nm CPU's, Easy Energy Saver is able to provide exceptional levels of power savings and enhanced power efficiency without sacrificing computing performance.
    • Product Description: Gigabyte GA-G31M-ES2L, motherboard, micro ATX, iG31
    • Product Type: Motherboard
    • Form Factor: Micro ATX
    • Dimensions (WxDxH): 9.6 in x 7.6 in
    • Chipset Type: Intel G31 Express / Intel ICH7
    • Multi-Core Support: Dual-Core / Quad-core
    • Max Bus Speed: 1600 MHz
    • Processor: 0 ( 1 ), LGA775 Socket
    • Compatible Processors: Core 2 Duo, Core 2 Quad, Pentium Dual Core, Celeron 400 sequence, Celeron Dual Core
    • 64-bit Processors Compatibility: Yes
    • RAM: 0 MB (installed) / 4 GB (max)
    • Supported RAM Technology: DDR2 SDRAM
    • Storage Controller: ATA-100, Serial ATA-300
    • USB Ports Configuration: 8 x USB
    • Storage Ports Configuration: 1 x ATA, 4 x SATA
    • Graphics Controller: Intel GMA 3100, Dynamic Video Memory Technology 4.0
    • Audio Output: Sound card, 7.1 channel surround
    • Networking: Network adapter, Realtek RTL8111C, Ethernet, Fast Ethernet, Gigabit Ethernet

    General
    Product Type: Motherboard
    Form Factor: Micro ATX
    Width: 9.6 in
    Depth: 7.6 in
    Compatible Processors: Core 2 Duo, Core 2 Quad, Pentium Dual Core, Celeron 400 sequence, Celeron Dual Core
    64-bit Processors Compatibility: Yes
    Processor Socket: LGA775 Socket
    Multi-Core Support: Dual-Core / Quad-core
    Chipset Type: Intel G31 Express / Intel ICH7
    Max Bus Speed: 1600 MHz
    BIOS Type: Award
    Storage Controller: ATA-100, Serial ATA-300
    Power Connectors: 4-pin ATX12V connector, 24-pin main power connector
    Processor
    Installed Qty (Max Supported): 0 ( 1 )
    Memory
    Supported RAM Technology: DDR2 SDRAM
    RAM Installed ( Max ): 0 MB / 4 GB (max)
    Supported RAM Speed: PC2-6400, PC2-5300, PC2-8500
    RAM Features: Two DDR channels
    Video
    Graphics Controller: Intel GMA 3100
    Video Memory: Dynamic Video Memory Technology 4.0
    Audio
    Audio Output: Sound card
    Audio Codec: Realtek ALC883
    Sound Output Mode: 7.1 channel surround
    Compliant Standards: High Definition Audio
    Telecom / Networking
    Networking: Network adapter, Realtek RTL8111C, Ethernet, Fast Ethernet, Gigabit Ethernet
    Features
    BIOS Features: DMI 2.0 support, ACPI 1.0b support, SMBIOS 2.4 support
    Hardware Monitoring: CPU core temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection
    Hardware Features: Chassis intrusion detection, Q-Flash, C.O.M. (Corporate Online Management), Virtual Dual BIOS, GIGABYTE Easy Energy Saver
    Expansion / Connectivity
    Expansion Slot(s): 1 processor, LGA775 Socket , 2 memory ( 1.8 V ), DIMM 240-pin , 1 PCI Express x16 , 1 PCI Express x1 , 2 PCI
    Storage Interfaces: Intel ICH7 : Serial ATA-300, connector(s): 4 x 7pin Serial ATA, 4 device(s) , Intel ICH7 : ATA-100, connector(s): 1 x 40pin IDC, 2 device(s)
    Interfaces: 1 x audio, line-in, 4 pin MPC , 1 x storage, floppy interface, 34 pin IDC , 1 x keyboard, generic, 6 pin mini-DIN (PS/2 style) , 1 x mouse, generic, 6 pin mini-DIN (PS/2 style) , 1 x parallel
    Additional Connectors (Optional): 4 x Hi-Speed USB
    Miscellaneous
    Cables Included: 1 x IDE cable , 1 x floppy cable , 2 x Serial ATA cable
    Software Included: Drivers & utilities, Norton Internet Security, @BIOS, Xpress Recovery 2
    Compliant Standards: Plug and Play, ACPI 1.0b, RoHS
