The new ADSL HWIC provides 1-port ADSL connectivity to a WAN. The single-port ADSL HWIC, combined with the Cisco 1841 integrated services router (ISR) and the Cisco 2800 and 3800 series integrated services routers (ISRs), provides high-speed digital data transmission between customer premises equipment (CPE) and a central office. This enables service providers and resellers to offer additional services by supporting features for business-class security, voice integration, differentiated classes of service (CoS), and managed network access with Cisco IOS Software. These value-added features, along with the manageability and reliability of Cisco IOS Software technology, provide the mission-critical networking that businesses require.
Features
Type: DSL modem, HWIC
Enclosure Type: Plug-in module
Max Transfer Rate: 24 Mbps
Warranty: 90 Days
Cisco WAN Interface Card High-Speed Specifications
Part # HWIC-1ADSL=
Manufacturer
Cisco
Device Type
DSL modem, HWIC
Enclosure Type
Plug-in module
Max Transfer Rate
24 Mbps
Digital Signaling Protocol
ADSL, ADSL2, ADSL2+
Protocols & Specifications
ITU G.992.3 (G.DMT.bis), ITU G.992.5, ITU G.992.1 (G.DMT) Annex A
Interface Type
HWIC
Connectivity Technology
Wired
Framing Format
ANSI T1.413
Interfaces
1 x modem, ADSL2+, RJ-11
Compatible Slots
1 x HWIC
Dimensions (WxDxH)
3.1" x 4.7" x 0.7"
Weight
3.2 oz
Warranty
90 Days
