Cisco Switching Module

1022547347   Cisco
Free Shipping on Orders over $99!
SKU # DS-X9248-96K9=
Your Price:
$7704.74

Quantity:

QTY 2 to 5
$7652.99

QTY 6 to 10
$7627.12

QTY 11+
$7601.25

Availability: In-Stock



Imageicon


For high-performance storage networking environments, the Cisco MDS 9000 family 48-port 8-Gbps fiber channel switching module delivers an ideal balance of performance and scalability. Its 48 autosensing 1/2/4/8-Gbps ports deliver a total of 192 Gbps of full-duplex bandwidth to meet the performance demands of enterprise-class or highly virtualized servers. Through easy-to-use traffic engineering capabilities, the 48-port 8-Gbps fiber channel switching module offers the flexibility to provide predictable high-performance storage and inter-switch connectivity, fully utilizing the available bandwidth.
  • Product Description: Cisco Switching Module switch, 48 ports, managed, plug-in module
  • Device Type: Switch, 48 ports, managed
  • Enclosure Type: Plug-in module
  • Ports: 48 x 8Gb Fibre Channel
  • Routing Protocol: VRRP
  • Remote Management Protocol: RMON, SNMP 3, SSH-2
  • Features: Hot swap module replacement, routing, auto-sensing per device, Syslog support, LUN zoning, Access Control List (ACL) support, Quality of Service (QoS)
  • Dimensions (WxDxH): 14 in x 16 in x 1.2 in
  • Weight: 10.4 lbs
  • System Requirements: Cisco NX-OS 4.1 or later

General
Device Type: Switch, 48 ports, managed
Enclosure Type: Plug-in module
Compatible Slots: 1 x expansion slot
Ports: 48 x 8Gb Fibre Channel
Fibre Channel: FC-AL, FC-AL-2, FC-BB, FC-DA, FC-FLA, FC-FS, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PLDA, FC-SB-2, FC-SB-3, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FC-SP, FC-BB-2, FCP, FCP-2, FC-PI-2,
Routing Protocol: VRRP
Remote Management Protocol: RMON, SNMP 3, SSH-2
Encryption Algorithm: AES
Authentication Method: RADIUS, TACACS+, Secure Shell v.2 (SSH2), DH-CHAP
Features: Hot swap module replacement, routing, auto-sensing per device, Syslog support, LUN zoning, Access Control List (ACL) support, Quality of Service (QoS)
Status Indicators: Port status, power, system
Expansion / Connectivity
Interfaces: 48 x SFP (mini-GBIC)
Miscellaneous
Width: 14 in
Depth: 16 in
Height: 1.2 in
Weight: 10.4 lbs
Compliant Standards: CE, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 3260, ICES-003 Class A,
Software / System Requirements
OS Required: Cisco NX-OS 4.1 or later
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 10, 90%
