3Com Baseline 2024 Ethernet Switch

1011274853   3COM
Free Shipping on Orders over $99!
SKU # 3C16471B-US
Please Call! 1-800-814-5410



Imageicon


The 3Com Baseline Switch 2024 is a 24-port unmanaged, 10/100 nonblocking switch designed for small to midsize offices. This rack mountable, business-class switch can be installed in a wiring closet or as a free-standing unit. The switch comes preconfigured for fast, easy installation using economical copper wiring. Auto-negotiation adjusts the port speed to match the communicating device. Any of the switch's 24 ports can deliver 10BASE-T Ethernet for users with average bandwidth requirements, or 100BASE-TX Fast Ethernet for power users or those with newer network connections. To simplify connecting cables, all ports come with automatic detection of the Ethernet cable type (MDI/MDIX). Like all 3Com Baseline products, this switch provides powerful, feature-rich practicality in a sturdy package designed for reliability, long life, and low total cost of ownership.
  • Product Description: 3Com Baseline Switch 2024, switch, 24 ports
  • Device Type: Switch
  • Form Factor: External, 1U
  • Dimensions (WxDxH): 17.3 in x 6.8 in x 1.7 in
  • Weight: 3.5 lbs
  • Localization: United States
  • Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX
  • Data Transfer Rate: 100 Mbps
  • Data Link Protocol: Ethernet, Fast Ethernet
  • Communication Mode: Half-duplex, full-duplex
  • Features: Auto-sensing per device, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward
  • Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.3x
  • Power: AC 120/230 V ( 50/60 Hz )

General
Device Type: Switch
Enclosure Type: External - 1U
Width: 17.3 in
Depth: 6.8 in
Height: 1.7 in
Weight: 3.5 lbs
Localization: United States
Networking
Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX
Data Transfer Rate: 100 Mbps
Data Link Protocol: Ethernet, Fast Ethernet
Connectivity Technology: Wired
Communication Mode: Half-duplex, full-duplex
Switching Protocol: Ethernet
MAC Address Table Size: 4K entries
Status Indicators: Port status, port transmission speed, port duplex mode, power
Features: Auto-sensing per device, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.3x
Expansion / Connectivity
Interfaces: 24 x network - Ethernet 10Base-T/100Base-TX - RJ-45
Miscellaneous
Rack Mounting Kit: Included
Compliant Standards: FCC Class A certified, CISPR 22 Class A, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, FCC Part 15, ICES-003 Class A, RoHS, UL 60950-1, IEC 6095
Power
Power Device: Power supply - internal
Voltage Required: AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 10 Watt
Manufacturer Warranty
Service & Support: 3 years warranty
Service & Support Details: Limited warranty - replacement - 3 years - shipment - response time: next business day ¦ Technical support - phone consulting - 90 days
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 10 - 95%
